Part Names and Functions

Multi-function keys
: Up/Down key
f/g
Move the cursor or contents etc.
upward or downward.
Display the i-Widget/Search
phonebook menu screen.
h/j : Left/Right key
Move the cursor to the left or right.
Display the Received call
history/Redial.
d : OK key
Perform the function
displayed on this key.
key
i
Display the main menu.
key
o
Display the mail menu.
Start key
r
Make calls.
Dial keys
Enter phone numbers or characters.
/Public mode (Drive mode) key
w
Set Public mode (Drive mode).
Quick key
Q
Activate a function selected
in "Quick button set".
<Using Earphone>
Connect an external-connector-terminal-
compatible earphone (optional). To use
an incompatible earphone, connect an
adapter converter (optional).
Charge lamp
Illuminance sensor
Detect brightness. Do not cover
with hand or put sticker on it.
Earpiece
Hear other party's voice from here.
Display (Touchscreen)
key
u
Display the still image
shooting screen.
key
p
Display the iMenu.
Back (Clear)/i-Channel key
t
Return to the previous
step or delete the
entered characters.
Display i-Channel.
Power/End/Hold key
y
/Manner key
q
Multi key
m
Display the TASK MENU screen.
3D key
A
Display the screen in 3D.
Mouthpiece/Microphone
Stereo Earphone/Microphone 01 for External
connector terminal (optional) connection example
The AC adapter (for charging) and the Stereo Earphone/Microphone 01
(earphone/microphone terminal) use the same slot.
Stereo Earphone/
Microphone 01
AC adapter
5
