Comtech EF Data KST-2000B Installation And Operation Manual page 171

Ku-Band Satellite Transceiver
FSK Remote Control Commands
Parameter Command
Type (Instruction
Code and
qualifier)
Parameter Command
Type (Instruction
Code and
qualifier)
Up Converter n.a.
Stored Faults
Down Converter n.a.
Stored Faults
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is, ASCII
Response to codes between 48 and 57)
Query
Where:
2W SSPA – Item D=BV1
8W SSPA – Item D=BV1|BV2|BV3
16W SSPA – Item D=BV1|BV2|BV3|BV4|BV5
25W SSPA – Item D=BV1|BV2|BV3|BV4|BV5|BV6|BV7|BV8|BV9
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is,
Response to ASCII codes between 48 and 57)
Query
6 bytes Query only.
<add/USF?X'cr'
>add/USF=ABCDEF'cr''lf' or
>add/USF=NO_FAULT'cr''lf'
Where: A=Overtemperature Status, 0=OK, 1=FLT
B=S-Band Synthesizer Lock Status, 0=OK, 1=FLT
C=Ku-Band Synthesizer Lock Status, 0=OK, 1=FLT
D=Latched S-Band Synthesizer Lock Status,
0=OK, 1=FLT
E=Latched Ku-Band Synthesizer Lock Status,
1=FLT
F=Interprocessor comm.Status, 0=OK, 1=FLT
X=Stored Fault Locations (0 to 9)
6 bytes Query only.
<add/DSF?X'cr'
>add/DSF=ABCDEF'cr''lf' or
>add/DSF=NO_FAULT'cr''lf'
Where: A=Overtemperature Status, 0=OK, 1=FLT
B=L-Band Synthesizer Lock Status,
0=OK, 1=FLT
C=Ku-Band Synthesizer Lock Status,
Response to Command (target to
controller)
USF= (message ok)
USF? (received ok, but invalid arguments
found)
USF* (message ok, but not permitted in
current mode)
0=OK,
DSF= (message ok)
DSF? (received ok, but invalid arguments
found)
DSF* (message ok, but not permitted in
current mode)
E-19
Revision 9
MN/KST2000AB.IOM
Response to Command (target to
controller)
Query
(Instruction
Code and
qualifier)
Query
(Instruction
Code and
qualifier)
USF?
DSF?
