Comtech EF Data KST-2000B Installation And Operation Manual page 169

Ku-Band Satellite Transceiver
FSK Remote Control Commands
Parameter Command
Type (Instruction
Code and
qualifier)
Concise Common n.a.
Equipment Status
Concise n.a
Reference Status
Concise AGC n.a.
Status
Automatic Gain AGC=
Control
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is,
Response to ASCII codes between 48 and 57)
Query
4 bytes Query only.
<add/CES?'cr'
>add/CES=ABCD'cr''lf'
Where: A=-7V PS Status, 0=OK, 1=FLT
B=+7V PS Status, 0=OK, 1=FLT
C=+12V PS Status, 0=OK, 1=FLT
D=+17V PS Status, 0=OK, 1=FLT
6 bytes Query only.
<add/CRS?'cr'
>add/CRS=ABCDEF'cr''lf'
Where: A=REF Source, 0=INT, 1=EXT
B=Oscillator State, 0=COLD, 1=WARM
C=72M Lock Status, 0=OK, 1=FLT
D=EXT REF Lock Status, 0=OK, 1=FLT, 2=NA
E=EXT REF Phase_N Status, 0=OK, 1=FLT, 2=NA
F= EXT REF Range Status, 0=OK, 1=FLT, 2=NA
Note: IF REF source is INT, then D, E, F, shall be 2 (NA).
3 bytes Query only.
<add/CAS?'cr'
>add/CAS=ABC'cr''lf'
Where: A=Loop Convergence, 0=OK, 1=FLT
B=Excessive Input Power (EIP), 0=OK, 1=FLT
C=Insufficient Input Power (IIP), 0=OK, 1=FLT
1 byte Command or Query
<add/AGC=x'cr'
>add/AGC='cr''lf'
<add/AGC?'cr'
>add/AGC=x'cr''lf'
Where = X = 0 (Unlock)
1 (Lock)
Response to Command (target to
controller)
CES= (message ok)
CES? (received ok, but invalid arguments
found)
CES* (message ok, but not permitted in
current mode)
CRS= (message ok)
CRS? (received ok, but invalid arguments
found)
CRS* (message ok, but not permitted in
current mode)
CAS= (message ok)
CAS? (received ok, but invalid arguments
found)
CAS* (message ok, but not permitted in
current mode)
AGC= (message ok)
AGC? (received ok, but invalid arguments
found)
AGC* (message ok, but not permitted in
current mode)
E-17
Revision 9
MN/KST2000AB.IOM
Query
(Instruction
Code and
qualifier)
CES?
CRS?
CAS?
AGC?
