Comtech EF Data KST-2000B Installation And Operation Manual page 159

Ku-Band Satellite Transceiver
FSK Remote Control Commands
Parameter Command
Type (Instruction
Code and
qualifier)
Up Converter UFQ=
Frequency
Down Converter DFQ=
Frequency
Up Converter UAT=
Attenuation
Down Converter DAT=
Attenuation
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is,
Response to ASCII codes between 48 and 57)
Query
7 bytes Command or Query.
<add/UFQ=nnnnn.n'cr'
>add/UFQ='cr''lf'
<add/UFQ?'cr'
>add/UFQ=nnnnn.n'cr''lf'
Where: nnnnn.n = 13750.0 to 14500.0 MHz, in 1 MHz steps
7 bytes Command or Query.
<add/DFQ=nnnnn.n'cr'
>add/DFQ='cr''lf'
<add/DFQ?'cr'
>add/DFQ=nnnnn.n'cr''lf'
Where: nnnnn.n = 10950.0 to 12750.0 MHz, in 1 MHz steps
4 bytes Command or Query.
<add/UAT=nn.n'cr'
>add/UAT='cr''lf'
<add/UAT?'cr'
>add/UAT=nn.n'cr''lf'
Where: nn.n = 00.0 to 20.0 dB, in 1.0 dB steps
4 bytes Command or Query.
<add/DAT=nn.n'cr'
>add/DAT='cr''lf'
<add/DAT?'cr'
>add/DAT=nn.n'cr''lf'
Where: nn.n = 00.0 to 10.0 dB, in 1.0 dB steps
Response to Command (target to
controller)
UFQ= (message ok)
UFQ? (received ok, but invalid arguments
found)
UFQ* (message ok, but not permitted in
current mode)
DFQ= (message ok)
DFQ? (received ok, but invalid arguments
found)
DFQ* (message ok, but not permitted in
current mode)
UAT= (message ok)
UAT? (received ok, but invalid argument
found)
UAT* (message ok, but not permitted in
current mode)
DAT= (message ok)
DAT? (received ok, but invalid arguments
found)
DAT* (message ok, but not permitted in
current mode)
E-7
Revision 9
MN/KST2000AB.IOM
Query
(Instruction
Code and
qualifier)
UFQ?
DFQ?
UAT?
DAT?
