Comtech EF Data KST-2000B Installation And Operation Manual page 122

Ku-Band Satellite Transceiver
Terminal Mode Commands
8 Watt SSPAs Command
Stored Faults Response
16 Watt SSPAs Command
Stored Faults Response
<add/HSF_#'cr'
>add/HSF_#'cr'
RF_yyy'cr'
HPA_xxx'cr'
BV1_xxx'cr'
BV2_xxx'cr'
BV3_xxx'cr'
+9.75V_xxx'cr'
-5V_xxx'cr'
PROG_xxx'cr''lf']
SFLT_#'cr''lf']
<add/HSF_#'cr'
>add/HSF_#'cr'
RF_yyy'cr'
HPA_xxx'cr'
BV1_xxx'cr'
BV2_xxx'cr'
BV3_xxx'cr'
BV4_xxx'cr'
BV5_xxx'cr'
+9.75V_xxx'cr'
-5V_xxx'cr'
PROG_xxx'cr'
SFLT_#'cr''lf']
B–12
Where: # = 0 to 9
HSF_# NO_FAULT or
RF Output (ON/OFF) Actual Status
HPA Converge Module (OK/FLT)
Bias Voltage #1 (OK/FLT)
Bias Voltage #2 (OK/FLT)
Bias Voltage #3 (OK/FLT)
+9.75 Volt power Supply (OK/FLT)
–5 Volt Power Supply (OK/FLT)
Inter-Processor Communications (OK/FLT)
Number of Stored Faults (# = 0 to 10)
The following response is from an OEM SSPA only:
HPA_xxx'cr' HPA Converter Module
(OK/FLT)
The following responses are from an OEM TWTA only:
HPA_xxx'cr' HPA Converter Module
(OK/FLT)
TEMP_xxx'cr' Temperature (OK/FLT)
HV_xxx'cr' High Voltage (ON/OFF)
Where: # = 0 to 9
HSF_# NO_FAULT or
RF Output (ON/OFF) Actual Status
HPA Converge Module (OK/FLT)
Bias Voltage #1 (OK/FLT)
Bias Voltage #2 (OK/FLT)
Bias Voltage #3 (OK/FLT)
Bias Voltage #4 (OK/FLT)
Bias Voltage #5 (OK/FLT)
+9.75 Volt power Supply (OK/FLT)
–5 Volt Power Supply (OK/FLT)
Inter-Processor Communications (OK/FLT)
Number of Stored Faults (# = 0 to 10)
The following response is from an OEM SSPA only:
HPA_xxx'cr' HPA Converter Module
(OK/FLT)
The following responses are from an OEM TWTA only:
HPA_xxx'cr' HPA Converter Module
(OK/FLT)
TEMP_xxx'cr' Temperature (OK/FLT)
HV_xxx'cr' High Voltage (ON/OFF)
Revision 9
MN/KST2000AB.IOM
