Ku-Band Satellite Transceiver
Terminal Mode Commands

B.3.6 Miscellaneous

Monitor and Control Command
Firmware Information Response
Up Converter Command
Firmware Information Response
Down Converter Command
Firmware Information Response
HPA Firmware Command
Information Response
Query Serial Status
Numbers Response
Query Assembly Command
Numbers Response
TWTA Heater Command
Response
Status
Response
TWTA Fault Reset Command
Response
Equipment Type Command
Response
HPA Connector Command
Location Response
<add/MCFI_'cr'
>add/MCFI_'cr'
VER_xxx.yyy.zzz'cr'
FW/nnnnn-ddr'cr'
mm/dd/yy'cr''lf']
<add/UFI_'cr'
>add?UFI_'cr'
VER_xxx.yyy.zzz'cr'
FW/nnnnn-ddr'cr'
mm/dd/yy'cr''lf']
<add/DFI_'cr'
>add/DFI_'cr'
VER_xxx.yyy.zzz'cr'
FW/nnnnn-ddr'cr'
mm/dd/yy'cr''lf']
<add/HFI_'cr'
>add/HFI_'cr'
VER_xxx.yyy.zzz'cr'
FW/nnnnn-ddr'cr'
mm/dd/yy'cr''lf']
<add/SNUM_'cr'
>add/SNUM_'cr'
UC_xxxxxxxxx'cr'
HPA_xxxxxxxxx'cr'
DC_xxxxxxxxx'cr'
M&C_xxxxxxxxx'cr''lf']
<add/ANUM_'cr'
>add/ANUM_'cr'
UC_AS/nnnnn-ddr'cr'
HPA_AS/nnnnn-ddr'cr'
DC_AS/nnnnn-ddr'cr'
M&C_AS/nnnnn-ddr'cr''lf']
<add/HTR_xxx'cr'
>add/HTR_xxx'cr''lf']
<add/HTR_'cr'
>add/HTR_xxx'cr''lf']
<add/TWTR_'cr'
>add/TWTR_RESET'cr''lf']
<add/ET_'cr'
>add/ET_ttttttttt_xxx.yyy.zzz'cr''lf']
Example: >1/ET_KST-2000A_1.1.1
<add/HCL2_'cr'
>add?HCL2_xxx'cr''lf']
B–14
Where:
xxx.yyy.zzz = Software version number (0.0.0 to
999.999.999)
nnnnn = Firmware number (0 to 99999)
dd = Firmware dash number (0 to 99)
r = Firmware revision (-, or A to Z)
Where:
xxx.yyy.zzz = Software version number (0.0.0 to
999.999.999)
nnnnn = Firmware number (0 to 99999)
dd = Firmware dash number (0 to 99)
r = Firmware revision (-, or A to Z)
Where:
xxx.yyy.zzz = Software version number (0.0.0 to
999.999.999)
nnnnn = Firmware number (0 to 99999)
dd = Firmware dash number (0 to 99)
r = Firmware revision (–, or A to Z)
Where:
xxx.yyy.zzz = Software version number (0.0.0 to
999.999.999)
nnnnn = Firmware number (0 to 99999)
dd = Firmware dash number (0 to 99)
r = Firmware revision (–, or A to Z)
Where:
xxxxxxxxx = Serial Number ( 0 to 999999999)
Where: nnnnn = Assembly number (0 to 99999)
d = Dash number (0 to 9)
r = Revision (–, or A to Z)
Where: xxx = WRM or HOT
Default = HOT
or N/A if TWTA is not HPA type
Note: This clears out any existing faults for a connected
TWTA.
Where: ttttttttt = Equipment Type
xxx.yyy.zzz = Software Version
Where: CEFD-SSPA
OEM-SSPA
OEM-TWTA
N/C (Not Connected)
This command returns the current location of the SSPA
M&C cable.
