KS- 6115
Fanless Touch Terminal
w/ Slim Base
User's Manual
Original
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Inc. expressly disclaims any
warranties, expressed, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw or http://www.posiflexusa.com
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2006
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 16520901010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS-6115 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX KS-6115

  • Page 1 KS- 6115 Fanless Touch Terminal w/ Slim Base User’s Manual Original FCC Notes: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery. Please always follow local environmental protection l a ws / regulations for disposal of used batteries and always replace only with battery of same type.
  • Page 3: Product Pictures

    INTRODUCTION PRODUCT PICTURES Front Views Side Views Rear View Bottom View PARTS IDENTIFICATION 1. Main unit 2. Touch panel / LCD panel 3. Optional side mount kit e.g. SD-400 4. Power indicator 5. Slim base stand 6. Cable cover 7. Removal hollow in cable cover Part 3...
  • Page 4: Product Features

    8. Lock / release lever for tilt angle adjust 9. Lock / release button for main unit detach 10. Touch open cover 11. Power switch 12. Brightness adjust thumb wheel 13. Touch open door latch 14. PS/2 KB port 15. Rear connect cover 16.
  • Page 5 8. one 5.5/2.5 coaxial type DC 12 V power input connector 9. one CF card reader slot or optional IDE + power connectors for HDD in base m) Touch control functions : left/right button, double click, drag & draw VGA memory size shared from system memory (8 ~ 254 MB) Support high performance DDR DRAM with maximum memory size 1GB in one module Integrated structure for side mount upgrade kit SD-400 with software...
  • Page 6: Opening Cable Cover

    INSTALLATION GUIDES CAUTION: Before any installation or cable connection to the set, please always make certain that the system is turned off and the external power source to the set is removed to prevent electric hazard! Never touch any metal pin in the connectors or circuits to avoid high voltage hazard or electrostatic discharge damage unless the operator is well grounded.
  • Page 7: Separating Main Unit

    SEPARATING MAIN UNIT In order to settle the touch terminal properly in a point of sale system, all the cable connections have to be routed through its base, either slim or universal. Therefore, please observe the procedures from A to C below to separate the main unit from both slim and universal base stand assembly after all cables in cable cover disconnected.
  • Page 8: Cable Passage

    4. Velcro Strap 5. Cable Passage To Main Unit For Desktop Mount Application 6. Cable Passage To Main Unit For Wall Mount Application 7. HDD Bracket Fixing Screw CABLE PASSAGE Please route all cables through the cable passage to main unit in desktop mount application.
  • Page 9: Base Mount Upgrade Kit

    main unit to slide down the winding grooves in the wall mount backpack - originally the base box. The stand assembly is not engaged in wall mount operation. Connect all cables coming out of the backpack through the wall mount application cable passage into the cable cover area of main unit. The area required for wall mount application is determined by the main unit dimensions and is 381 mm in width and 305 mm in height.
  • Page 10: Routing The Cables

    outside of the bottom plate from inside as circled in the right picture that is the bottom view of the base stand. Then use the 4 larger screws to fix the monitor support rod from bottom as arrowed in the same picture. Route the VGA through the cable exit of the base stand to the main unit.
  • Page 11: Desktop Mounting

    For desk top/counter application, the body of KS-6115 occupies a space of 381 mm wide, 265 mm deep and 258 to 355 mm high per main unit tilt angle.
  • Page 12: Operating System Recovery

    OPERATING SYSTEM RECOVERY For KS systems with operating system in the Compact Flash Card, once the Compact Flash is damaged for any reason, the thin client may fail to boot. A bootable new Compact Flash Card will be required to have the workstation back to work.
  • Page 13: Application Environment

    USING THE TOUCH TERMINAL APPLICATION ENVIRONMENT It is very important that you check the following operational guidelines: Ventilation This terminal must NOT be operated in an environment with restricted ventilation. There must be at least 25 mm air clearance around any top or side ventilation holes with a free flow of air around the unit at ALL times for the installation.
  • Page 14 Power Indicator The power status of the system is indicated by the backlighted logo. When the logo lights in green, the AC power is standby for the system to turn on. The logo turns to blue when the system is powered on. Hardware Power Switch The power switch located in the touch open cover of the main unit is a tactile pushbutton switch.
  • Page 15: Display Issues

    DISPLAY ISSUES Main LCD Display For best viewing result please set your display resolution at 1024 x 768 with high color. In configuration of system memory, max. 254 MB can be shared as the video memory. VGA Port The VGA port in the KS system supports TM4115 touch monitor, LM6212 LCD monitor or TM7112 touch monitor if there is no base mount 2 LCD display.
  • Page 16: Touch Panel

    TOUCH PANEL All paragraphs below are applicable for models with touch panel only. The user of those models without touch panel can ignore them and consider this user’ s manual ends here. Mouse Emulation The touch panel in KS system uses USB interface. When the touch driver is properly installed, this touch panel works exactly like a standard mouse for both interfaces.
  • Page 17 A program named “Posiflex Touch Terminal Manager” and a right- click sticky button tool in the program group “Posiflex Tools” is installed in the preloaded Windows system with a PS/2 interface touch panel controller. This program can also be obtained by download from the POSIFLEX web site. Part 17...
  • Page 18 Part 18...
  • Page 19 Part 19...
  • Page 20 ĵ§i¨Ï¥ÎªÌ T31454 ³o¬O¥ÒÃþªº¸ê°T²£«~ ¡A ¦ b©~¦íªºÀô ¹Ò¤¤¨Ï¥Î®É ¡A ¥ i¯à·|³y¦¨®gÀW¤z ÂZ ¡ A ¦ b³oºØ±¡ªp¤U ¡A ¨ ϥΪ̷|³Q-n ¨D±Ä¨ú¬Y¨Ç¾A·íªº¹ïµ¦ ¡C Part 20...
