POSIFLEX KS - 6815 User Manual

POSIFLEX KS - 6815 User Manual

Fan free touch terminal w/ slim base

Advertisement

KS - 6815
Fan Free Touch Terminal
w/ Slim Base
User's Manual
Rev.: Original
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex Technologies, Inc. will assume no liability for any technical inaccuracies or
editorial or other errors or omissions contained herein, nor for direct, indirect,
incidental, consequential or otherwise damages, including without limitation loss of
data or profits, resulting from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Technologies, Inc. expressly
disclaims any warranties, expressed, implied or statutory, including without limitation
implied warranties of merchantability or fitness for particular purpose, good title and
against infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex Technologies, Inc. reserves the
right to alter product designs, layouts or drivers without notification. The system
integrator shall provide applicative notices and arrangement for special options utilizing
this product. The user may find the most up to date information of the hardware from:
http://www.posiflex.com or http://www.posiflex.com.tw or http://www.posiflexusa.com
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Technologies, Inc. the publisher of this documentation.
© Copyright Posiflex Technologies, Inc. 2009
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 16590903010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS - 6815 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX KS - 6815

  • Page 1 About This Manual: Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex Technologies, Inc. will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. This product contains inside a Lithium battery. Please always follow local environmental protection laws / regulations for disposal of used batteries and always replace only with battery of same type.
  • Page 3: Product Pictures

    INTRODUCTION PRODUCT PICTURES Front Views Panel tilted straight With side mount kit Panel tilted back Side Views Right side view Inside touch open door Left side view Part 3...
  • Page 4: Parts Identification

    Rear & Bottom Views Rear view w/o Rear view w/ side & Bottom view upgrade kit rear top mount kit PARTS IDENTIFICATION 1. Main unit 2. Touch panel / LCD panel 3. Power indicator 4. Gen 5 slim base stand 5.
  • Page 5: Product Features

    PRODUCT FEATURES Standard Features: CPU: Intel Atom N270 1.6G FSB533 Cache512K Fan free structure with Aluminum die cast main unit casing for harsh environment Data storage device: SATA HDD 2.5” 80 GB in main unit or optional SSD in main unit or optional CF card reader adaptor & CF card in main unit or optional SATA HDD in base with optional RAID 1 control An advanced slim base design that supports 2 LCD display or pole...
  • Page 6 opportunist theft Touch control functions: left/right button, double click, drag & draw Dual display support (per OS capability) VGA memory size 8 MB shared from system memory supporting Dynamic video memory technology up to 224 MB Support high performance DDR2 SDRAM with maximum memory size 2GB in two SODIMM Integrated structure for side mount upgrade kit like SD-400Z with software programmable MSR parameters for WEPOS or Win XP pro...
  • Page 7: Opening Cable Cover

    CF card reader option is installed and installation of optional SATA HDD in base, optional RAID function reset. All these technical maneuver operations require purchase of applicable Technical Manual from Posiflex or consultation from Posiflex authorized dealers and should be handled only by a qualified technician. OPENING CABLE COVER Please follow steps A to C sequentially with reference to pictures below to remove the cable cover for both slim and universal base models.
  • Page 8: Separating Main Unit

    DISCONNECTING ALL CABLES After removal of the cable cover, the connector area will be accessible then. Please first note orientations of every existing cable connection and then disconnect every cable properly before separating the main unit from the adjustable stand assembly. Please note that the click lock spring has to be pressed down prior to pulling out the connector such as the LAN port or the CR port or the alternate RJ45 form COM3 port.
  • Page 9: Base Mount Upgrade Kit

    1. Cable Exit 2. UPS Battery Stopper 3. Cable Tie for Option HDD Cables 4. Cable Passage To Main Unit For Desktop Mount Application 5. UPS Battery End Hold 6. Option HDD Conversion Board Inside base bottom 7. Option HDD Bracket INSTALLING UPS BATTERY (OPTION) When the KS-6815 system is ordered with the UPS battery, the UPS battery is separately stored in the carton at delivery.
  • Page 10: Preparing The Main Unit

    12” 2 LCD Panel Or Customer Display Fit the joint base of PD-306 or PD-2501 or PD-2602 or LM-6101 to the rear connect cover opening. Please route the interface cable through the normal cable exit (under the joint base) as in the 2 pictures. Fit 2 screws through washers at the arrowed screw holes to hold the joint tight.
  • Page 11: Side Mount Upgrade Kit

    Please note that only those qualified technicians may adjust in the service window with information from Posiflex and the contents in the service window may change without notice as time develops. The option LPT conversion cable should be applied to the connector as marked in an ellipse in left picture below.
  • Page 12: Connecting Cables

    The RJ11 connector in I/O area of a KS-6815 system can be used for controlling most of the common cash drawers available on the market. However, it is most recommended to use Posiflex CR-2000 or CR-2200 or CR-3100 or CR-3200 or CR-4000 or CR-4100 or CR-4210 or CR-6310 for best compliance to operate the opening mechanism and to monitor the drawer open status.
  • Page 13: Desktop Mounting

    Connect the cables to appropriate external devices through the cable exit at the bottom of stand assembly. Please make sure that each connector has to be connected to the right device in the right way. CAUTION: On doing any insertion or extraction of any connector, please always hold the connector head itself instead of pulling on the cable wire.
  • Page 14: Operating System Recovery

    System Integrator to deal with such situations. For KS systems preloaded with Windows XP Pro / WEPOS / POS Ready on HDD, Posiflex provides recovery DVD delivered with the touch terminal for the preloaded operating system. The System Integrator shall take care of software restoration after OS recovered.
  • Page 15: Application Environment

    USING THE TOUCH TERMINAL APPLICATION ENVIRONMENT It is very important that you check the following operational guidelines: Ventilation This terminal must NOT be operated in an environment with restricted ventilation. There must be at least 25 mm air clearance around any top or side ventilation holes with a free flow of air around the unit at ALL times for the installation.
  • Page 16: Power On/Off

    wash immediately with water. If the acid comes in contact with eyes, rinse eyes with large amount of clean water and see a doctor immediately. A larger external battery may be connected to give an extended operation. Please check your dealer about this capability when required. WARNING: If there are any signs of over charging or leakage of electrolyte please contact your dealer immediately...
  • Page 17 In preloaded Windows, “Posiflex Power Switch Manager” in “Posiflex Tools” in the Program Files helps managing these functions. Software Support Features The KS series provides a software power off command for application program maneuvers.
  • Page 18: Brightness Control

    LM-6101, have a qualified technician to set the power supply in KS main unit through the VGA connector according to Posiflex technical information. Do not connect other monitor to this port before the power in this port is disabled.
  • Page 19: Serial Ports - Com1/2

    SERIAL PORTS – COM1/2/3 In KS-6815 system, there are 2 serial ports in form of DB 9 pin male connectors and 1 in form of 10 pin RJ45 type modular connector available. Both DB 9serial ports can supply a +5 V DC through pin 9 after proper BIOS setup.
  • Page 20 Posiflex USB Touch Manager A program named “Posiflex USB Touch Manager” and a right-click sticky button tool in the program group “Posiflex USB Touch Tools” is installed in the preloaded Windows system with a USB interface touch panel controller. This program can also be obtained by download from the POSIFLEX web site.
