Configuration Manual
Ascom d41 DECT Handset
The parameter settings affect the "normal" mode, that is, not wired headset, and not the
handsfree/loudspeaking mode.
For configuration of headset audio see,
Note: Changing these parameters may result in lower sound quality and high sound level.
Evaluate carefully before applying.

5.19 Headset Configuration

A headset is recommended if you frequently use the handset and/or want to have both
hands free. The headset comes in two versions, that is, microphone on boom and
microphone on cable.
5.19.1 Selection of Headset Type
In order to achieve optimal audio quality with the different headset types, it is
recommended to set the corresponding headset type. The default setting is "microphone on
a boom", which means that the audio is optimized for using a headset with microphone on a
boom. The headset type can be changed as follows:
1 Select Connections > Headset.
2 In the Headset type drop-down list, select the corresponding headset type to be
used.
If "User headset profile" is selected, continue with chapter
profile.
5.19.2 User headset profile
If the preconfigured headset profiles does not match the headset or the audio performance
is bad, it is possible to configure a headset profile.
1 Select Connections > Headset > User headset profile.
2 In the Name of user headset profile field, enter an appropriate name. The name will
be visible and selectable in the handset menu.
3 In the Headset mic adjustment drop-down list, select the microphone gain to be used.
4 In the Headset speaker adjustment drop-down list, select the speaker gain to be
used.
Note: Changing these parameters may result in a very high sound level which can cause
hearing damage. In addition, these parameters may result in lower sound quality such as
noise and echo. If the audio problems occur, it is noticeable for the person listening on the
conversation. Evaluate carefully before applying.
21 June 2012 / Ver. G
5.19 Headset Configuration.
TD 92641EN
5.19.2 User headset
25
