Configuration Manual
Ascom i75 VoWiFi Handset
4

Handset Installation

This section describes the recommended procedure to install several handsets in a large
system and to install a few handsets in a small system. There are several ways to install a
handset but the procedures described here guarantees simple maintenance of the system.
The procedure differs depending on the size of the system. For effective administration it is
recommended to use the PDM System version, but in small systems it is possible to
administer the handsets using only the PDM Windows version.
Installation steps in large VoWiFi Systems:
1 Create templates in the PDM System version; one with network settings and
another with common settings.
2 Create user numbers (handsets) and apply the templates.
3 Create a template with identical network settings in the PDM Windows version (for
log on of the handsets).
Installation steps in small VoWiFi Systems:
1 Create user numbers.
2 Create one template for all settings in the PDM Windows version.
4.1

Installation in Large Systems

When installing several handsets in a VoWiFi system, it is required to have both the PDM
System version and the PDM Windows version to make the maintenance and handling of
the system as simple as possible.
4.1.1

Create a Network Template in the PDM System version

Create one template which contains the network settings only. This must be done to
prevent the PDM System version from restoring the WLAN parameters to default during
the first synchronization.
Note: Only select the parameters that are changed, if all parameters are selected the
system performance decreases
1 Open the PDM System version.
2 Create a template with the network parameters:
• ESSID
• WLAN settings
• IMS IP address
Figure 5.
3 Save the network template in the PDM System version using a descriptive name.
4.1.2

Create a Common Template in the PDM System version

Create another template with the common settings (exclude the network settings)
applicable to all handsets. This template contains for example, hidden menu items in the
display, certain level of ring signal and vibrators.
1. All required system settings for the WLAN. For example Security mode and Encryption type.
2008-11-20/ Ver. B
1
TD 92431GB
5
