Configuration Manual
Ascom i75 VoWiFi Handset

8.12.3 Configure Soft Key

Three soft keys can be configured for each profile.
1 In the applicable profile, select Soft key X.
2 Enter the name of the soft key in the Soft key name text field.
3 Enter the applicable index in the Soft key index text field. Index parameters are used
with the Soft key functions "Shortcut", "Presence", "PTT" and "Change profile".
See the help text in the PDM for valid indexes.
Figure 18.
4 Select the applicable function in the Soft key function drop-down list.
• Default
• Disable - no function is used.
• Change profile
• Phone call
• Presence
• PTT
• Send data
• Send data with prefix
• Send message
• Short-cut
Figure 19.
5 Enter user data in the Soft key user data text field if applicable, see the help text in
the PDM.
Repeat the procedure to configure additional soft keys for selected profile.

8.12.4 Diversions

Calls can be diverted to other phone numbers, for example when busy.
1 In the applicable profile, select Diversions.
2 Activate a diversion by selecting "Enable" in the applicable diversion drop-down
lists. The following diversions are possible:
• Activate diversions for all calls
• Activate diversions on user busy
• Activate no answer diversions
3 Enter the diversion number in the applicable diversion number text field.

8.13 Active Profile

This setting defines the default profile.
1 Select UI > Settings.
2 Select the applicable profile in the Active profile drop-down list.
• Normal
• In Charger
• Profile 2
• Profile 3
• Profile 9
1. If the activity ID is changed in the Presence Management system the value for the Soft key index in the VoWiFi handset
needs to be re-programmed.
