Configuration Manual
Ascom i75 VoWiFi Handset
10

VoWiFi Handset Internal Web Administration Page

The internal web administration page for the handset makes it possible to:
• Download licences
on page 11 and
• Upgrade software, refer to
• Troubleshoot the VoWiFi System.
• View statistics, see below.
10.1 Access the Handset´s Internal Web Administration page
1 Enter the handset´s IP address in the address bar in the web browser to access the
internal web administration page for the handset. The IP address can be found in
the handset´s menu (Settings >System >Information).
The web administration page opens is the System Setup information view. The
following are shown:
• Software version
• MAC address
• Coder
• SNTP server
• Local time
• Uptime
Figure 2. The information view
2 Enter administration user name and administration password to access further
pages.
Default user name and password for an administrator:
• User name: admin
• Password: changeme

10.1.1 Show Detailed Information

1 Click the Detailed info link. The following information is shown:
• IP address
• Subnet mask
• Default gateway
• SIP proxy/H.323 gatekeeper IP address
1.Note that licences are associated with the handset, i.e. a new/replaced handset must be upgraded
2008-11-20/ Ver. B
1
for the alarm and location features, refer to
7 Add Location Features
12 Upgrade the Software
6 Add Alarm Features
on page 12.
on page 38.
TD 92431GB
33
