Matrix Switchers Control Program

Another way to operate the switcher is via the Matrix Switchers Control
Program, which runs on computers that use the Windows
system This program is available on the Extron website. You can run this
program from a PC connected to the rear panel Remote RS-232/RS-422
port (item on page 9), LAN port
C
configuration port (item
A
14400] on page 11) on the switcher.
NOTE: For details on operating the program, see the "Matrix
Software" section in the FOX Matrix 320x and FOX Matrix 14400
User Guide.

Installing the Program

The Matrix Switchers Control Program is available on the Extron website.
Download and install all programs as follows:
1. www.extron.com
Visit
2 2 2 2 2 2 2 2 2 2
2. Click the Software link.
3. Select the desired software to download and click Download .
TIP: Jump to the nearest page of downloads by clicking the
desired filtering letter.
The Download Center dialog box appears (see figure 8, on the next
page).
16 FOX Matrix 320x and FOX Matrix 14400 • Remote Control
operating
®
(item on page 9), or front panel
D
item
[ FOX Matrix 320x] or [FOX Matrix
B
and click the Download tab.
1 1 1 1 1 1 1 1 1 1
3 3 3 3 3 3 3 3 3 3
4 4 4 4 4 4 4 4 4 4
5 5 5 5 5 5 5 5 5 5
Figure 8. Download Center Dialog Box
4. Enter the requested personal information;
TIP: Click Remember Me to eliminate step 4 in future downloads.
5. Click Download to copy the software or firmware to your computer.
The download warns you about downloads and asks you to confirm
it.
NOTE: The figure above may appear different or may not
appear at all, depending on your web browser choice and its
security settings.
6. Cick Run to confirm that you want to run the installation.
7.
Follow the on-screen instructions. The installation program creates
the necessary directories and folders and installs the programs.

LAN Port Connection

The first time you connect your PC to the switcher via the LAN port,
you may need to change the default settings (IP address, subnet
mask, and [optional] administrator name and password) on the
controller (see the "Configuring for Network Communication" in the
FOX Matrix 320x and FOX Matrix 14400 User Guide.

Starting the Program

1. Click Start > Programs > Extron Electronics > Matrix
Switchers > MATRIX Switcher + Control Pgm .
FOX Matrix 320x and FOX Matrix 14400 • Remote Control
6 6 6 6 6 6 6 6 6 6
17
