Rosen Aviation 0700-104 Technical Manual

Remote display system
Hide thumbs
Table of Contents

Advertisement

Quick Links

ELECTRONIC REVISION
CONTROLLED
Document Number 105478 Rev F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 0700-104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosen Aviation 0700-104

Summary of Contents for Rosen Aviation 0700-104

  • Page 1 ELECTRONIC REVISION CONTROLLED Document Number 105478 Rev F...
  • Page 2 The information contained in this document is subject to change without notice. Because we are continuously improving and adding features to our products, Rosen Aviation, LLC reserves the right to change specifications without prior notice. Rosen Aviation, LLC shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Rosen Aviation Remote Display System Contents 1. INTRODUCTION .........................5 1.1. System Overview ......................5 1.2. System Components.....................6 1.2.1. Remote Inputs ........................6 2. VIDEO INPUTS ........................6 3. INSTALLATION GUIDELINES ...................7 3.1. Mounting Configurations ....................7 3.1.1. Bulkhead Mounting Requirements ..................7 4. ASSEMBLY INSTRUCTIONS FOR ACCESSORIES ............8 4.1.
  • Page 4 Rosen Aviation Remote Display System 10.1.6. Composite Sig (Signal) ....................24 10.1.7. AGC (Automatic Gain Control) ..................24 10.1.8. RJ45 Cable Compensation ................... 25 10.2. Mode Menu ....................... 25 10.2.1. Power Mode ......................... 25 10.2.2. Operation Mode ......................26 10.2.3. SDI Overscan ....................... 27 10.2.4.

  • Page 5: Introduction

    The RMEB operates one Remote Display Module (RDM)—the RMEB 0700-107 Mod 02 is the latest model, which replaces the RMEB 0700-104, and it operates all RDM sizes currently available from Rosen. Graphic Signal Input ...

  • Page 6: System Components

    Remote Monitor Electronics Box (RMEB)   RMEB (P/N 0700-104) operates 19-, 24-, 26-, and 32-inch RDMs  RMEB (P/N 0700-107 Mod 01) operates 19 through 42-inch RDMs  RMEB (P/N 0700-107 Mod 02) operates 19 through 55-inch RDMs Remote Display Modules (RDM) ...

  • Page 7: Installation Guidelines

    Rosen Aviation Remote Display System 3. INSTALLATION GUIDELINES 3.1. Mounting Configurations Rosen’s RDMs can be flush mounted, mounted with a sleek bezel (semi-proud), or proud- mounted between a bezel and cosmetic back. The photos below are representative of the different bulkhead mounting options for the remote displays. Please contact Rosen Sales for specific configurations.

  • Page 8: Assembly Instructions For Accessories

    Rosen Aviation Remote Display System 4. ASSEMBLY INSTRUCTIONS FOR ACCESSORIES This section provides instructions about how to assemble the cosmetic backs and bezels. To add a stylish, proud-mount option, mount the cosmetic back to the bulkhead, attach the RDM to the cosmetic back, and then snap on the bezel.

  • Page 9: Attaching An Rdm To A Cosmetic Back

    Rosen Aviation Remote Display System Attach the 32” cosmetic back to the bulkhead using six #6 100 FHP screws  (customer supplied). Attach the 42” cosmetic back to the bulkhead using ten #6 100 FHP screws  (customer supplied). Attach the 55” cosmetic back to the bulkhead using twelve #6 100 FHP screws ...

  • Page 10: Mounting A Bezel

    The RMEB outputs a serialized video signal via an RJ-45 cable from P4 and provides conditioned power and control to the RDM via a harness with DA15 connectors from P3. To obtain information about interconnect cables, please contact Rosen Aviation’s Technical Support at 541.434.4512 and request the Interconnect Cable Specification for Remote Electronics (P/N 105821).

  • Page 11: Pinout Connections

    Rosen Aviation Remote Display System 5.1. Pinout Connections There are several ways to connect the remote display system to an aircraft’s entertainment system. Follow the pinout descriptions on the technical drawings to assist in completing the wiring connections. Use the pinout information in the RS-485 Configuration Discretes table on the technical drawing (P/N 0700-107-CD) when operating in Auto SDI mode.

  • Page 12: Initial Power Up

    RMEB technical drawing. Also, avoid coiling the power wire as this can cause heat to build up in the wire. If you have more questions about Power Requirements, contact Rosen Aviation’s Technical Support at 541.434.4512.

  • Page 13: Ir Remote Control

    Rosen Aviation Remote Display System 8. IR REMOTE CONTROL The remote display system uses a remote control to adjust the on-screen display (OSD) settings. The instructions in this manual use the RC5 IR remote in describing how to navigate the OSD.

  • Page 14: Osd Menu Options

    Rosen Aviation Remote Display System 9. OSD MENU OPTIONS The OSD contains screen settings and options in menus and informational readouts that display over the image, as shown below. Press MENU on the remote to open the Main Menu, as shown in Section 9.1.

  • Page 15: User Menu

    Rosen Aviation Remote Display System 9.2. User Menu The Main Menu opens to the screen, shown in Figure 9 (above). Press the ► button to access the User menu options. Press ▼▲ buttons to select a User option and then press ENTER to change its value.

  • Page 16: Scheme

    Rosen Aviation Remote Display System Letterbox Expanded: Expands the source video in the vertical and horizontal dimensions to fill the display screen. Letterbox-format DVDs will have small or no bars showing in this mode, while 4:3 aspect video sources will expand beyond the screen boundaries and appear cropped.

  • Page 17: Auto Adjust

    Rosen Aviation Remote Display System 9.2.5. Auto Adjust (RGB only) Use Auto Adjust when the RGB source is active to force the display to evaluate the RGB signals and ensure that it is interpreting them correctly. To perform an Auto Adjust within the OSD, select the option and press ENTER. (From the remote, close the OSD and press the AUTO button.) The screen will briefly go black while the signals...

  • Page 18: Reset Scheme

    Rosen Aviation Remote Display System 9.3.3. Reset Scheme Restores the values of the current scheme to their default settings, and it affects only the current source. Use Reset Scheme to revert to the default screen colors if the other Image Adjust options did not correct the screen quality.
  • Page 19 Rosen Aviation Remote Display System 9.3.4.1.1. Color Levels: Red, Green, Blue Setting the Color Temperature to User will make the Red, Blue, and Green options active. Each color adjusts the low-level registers of its respective color value in the picture.
  • Page 20 Rosen Aviation Remote Display System 9.3.4.3. Image Position Submenu (RGB only) Use the Image Position options to center an RGB picture horizontally or vertically on the screen. Note: Changing the resolution, source, or cycling power will reset any adjustments to this submenu’s settings.

  • Page 21: Info

    Rosen Aviation Remote Display System 9.3.4.5. RGB Phase (RGB only) Use RGB Phase to adjust the default phase value used for RGB signals. Each RGB video source can have different phase values, which can result in the RGB video image appearing to jitter. RGB Phase enables you to adjust the RGB video image to eliminate jitter.

  • Page 22: Technician Menu

    Standard Operation Mode active RMEB 0700-104 RMEB 0700-107 Figure 23 Technician Main Menus To navigate the menu options, press the ▲ or ▼ buttons. To close the Technician menu and return to the Info Page, select the Back option and press MENU.

  • Page 23: Advanced Technician Menu

    Rosen Aviation Remote Display System 10.1. Advanced Technician Menu This submenu provides installers and technicians more advanced controls of the image. From the Technician Main Menu, highlight Advanced and then press ENTER. Available only on a 19” RDM NA indicates that a...

  • Page 24: Comp/Rgb 1

    Rosen Aviation Remote Display System 10.1.3. Comp/RGB 1 Use Comp/RGB 1 to specify which input source the Component/RGB channel 1 will use. The options for channel 1 to display are either Component or RGB. Highlight AdvancedComp/RGB 1 and press ENTER.

  • Page 25: Rj45 Cable Compensation

    Rosen Aviation Remote Display System 10.1.8. RJ45 Cable Compensation The technology employed to transmit full-rate, high-definition video over an RJ-45 cable may require an initial setup to ensure the highest possible image quality. Shorter cables (0-6 feet) and cables with different impedance characteristics than the Rosen-specified RJ-45 interconnect cable may benefit from turning off RJ45 Cable Comp.

  • Page 26: Operation Mode

    Rosen Aviation Remote Display System Power Mode cont. Options include the following:  Ground-On: The display always starts up in the ON state when the power pin is set to ground, and it ignores all power commands from the IR, RS-232, and RS- 485.

  • Page 27: Sdi Overscan

    Rosen Aviation Remote Display System When operating in Auto SDI mode, the RS-485 ID is configured via discretes; otherwise, it is configured via the network address. For more information, see the RS-485 Configuration Discretes table on page 2 of the technical drawing (P/N 0700-107-CD).

  • Page 28: Osd Timeout

    The splash screen appears for approximately eight seconds when 28V power is first applied to the display. When enabled, the Rosen Aviation splash screen appears; when disabled, the screen remains black. Highlight TechnicianSplash Screen and press ENTER.

  • Page 29: Source Mode

    Rosen Aviation Remote Display System 10.6. Source Mode (Available on RMEB 0700-107 when the Operation Mode is set to Standard) This submenu enables you to set the Source Select mode to a specific state: either Momentary switch mode, or Constant switch mode.

  • Page 30: Constant Mode

    Rosen Aviation Remote Display System 10.6.2. Constant Mode Constant enables you to specify the two sources the monitor will switch between when the constant switch goes between an open state and a ground state. Highlight TechnicianSource ModeSource Select and press ENTER.

  • Page 31: Technical References And Support

    Rosen Aviation Remote Display System 11. TECHNICAL REFERENCES AND SUPPORT Always check the Rosen Aviation website under the Products tab to ensure that you are working with the most current revision of technical documentation. 11.1. Troubleshooting If the display does not function properly, refer to the following troubleshooting table for symptoms and possible solutions before contacting Rosen Technical Support.

  • Page 32: Cleaning The Display

    Electronics If you need assistance in configuring a universal remote control to work with a remote display system, please contact Rosen Aviation Technical Support at 541.342.3802. 11.2. Cleaning the Display To clean the LCD, very gently wipe the screen with a clean, commercially approved LCD cleaning cloth and alcohol-free LCD cleaning solution.
  • Page 33 Rosen Aviation Remote Display System Description Section Category Comments Crash Safety (Sustained) 7.3.3 Vibration Random Vibration – Fixed Wing Aircraft 8.5.2 S (Curve B) Magnetic Effect Magnetic Effect 15.3 Power Input Normal Operating Conditions (DC) 16.6.1 Average Value Voltage (DC) 16.6.1.1...

  • Page 34: Other Certification Considerations For Rdms

    Rosen Aviation Remote Display System Description Section Category Comments Emission of Radio Frequency Energy Conducted RF Emission 21.4 Radiated RF Emission 21.5 Electrostatic Discharge (ESD) Electrostatic Discharge (ESD) 25.5 Flammability testing in accordance with 14 CFR Flammability 25.853 Appendix F 11.3.1.

  • Page 35: Dvi/Hdmi Standard Resolutions

    Rosen Aviation Remote Display System 11.4.2. DVI/HDMI Standard Resolutions 480i/29, 480i/30 480p/59, 480p/60 576i/25 576p/50 720p/50, 720p/59, 720p/60 1080i/25, 1080i/29, 1080i/30 1080p/23, 1080p/24, 1080p/25, 1080p/50, 1080p/60 11.4.3. VGA Resolutions 640x480p/60 VGA 800x600p/60 SVGA 1024x768p/60 XGA 1152x864p/60 1280x768p/60 WXGA 1360x768p/60 WXGA...

  • Page 36: Sdi Resolutions

    Rosen Aviation Remote Display System 11.4.6. SDI Resolutions 480i/29 576i/25 720p/50, 720p/59, 720p/60 1080i/25, 1080i/29, 1080i/30 1080p/23, 1080p/24, 1080p/25, 1080p/29, 1080p/30, 1080p/50, 1080p/59, 1080p/60 12. DEFINITIONS 3G HD-SDI Newer, high-definition serial digital interface with a single 2.970 G/bit/s serial link...
  • Page 37 Rosen Aviation Remote Display System RDM Remote Display Module RF Radio frequency RGB Red, Green, Blue RMEB Remote Monitor Electronics Box RS-232 Standard for serial binary data interchange RS-485 Standard for allowing multiple devices to share a common set of serial data communication lines.

  • Page 38: Revision History

    Rosen Aviation Remote Display System 13. REVISION HISTORY Revision E is limited to draft or prototype documents. Revisions I, O, Q, S, X and Z are not to be used. Revision Date Revision Description 04/24/12 Initial release 12-0219 10/03/12 12-0498 Add 42”...

This manual is also suitable for:

0700-107

Table of Contents
