• SMART Board software for installation on any computer. For more information on using the
various tools and applications included with SMART Board software, see the SMART Board
User's Guide or the SMART Board software Help.
The installation process varies slightly if you have a model that comes with a mirror stand.
However, the major steps for all installations include:
• preparing to install the interactive whiteboard (page 3)
• installing the interactive whiteboard (page 9)
• connecting the components (page 21)
• setting up the projector (page 25)
• preparing the interactive whiteboard for use (page 33)
After the installation sections in this guide, you'll find tips on using and caring for your interactive
whiteboard, and information on using it. Specification drawings for each model are also included,
starting on page 43.
Note for 2865 or 2965 owners
If you have a 2865 or a 2965, you'll also have to set up the mirror stand (page 16) and the
projector (page 26). The mirror stand is specially designed to project a square image on the
screen. However, you must install the stand a short distance from the back of the interactive
screen.
• For the 2865, the maximum distance between the lower cabinet of the mirror stand and the
wall surface upon which you mount the interactive whiteboard is 3 1/4" (8.3 cm).
• For the 2965, you must allow at least 15" (38.1 cm) between the lower cabinet of the mirror
stand and the wall surface upon which the interactive whiteboard is mounted.
Both the 2865 and the 2965 include an NEC MT1065 projector with a custom short-throw lens.
With the standard lamp, you can use one of its two available modes: Normal and Eco. Normal
mode is the default and recommended setting, which provides 100% brightness. Eco mode
reduces the brightness to 80%, but increases lamp longevity and conserves power. An optional
extended-life lamp is also available.
You'll find some cleaning instructions for the MT1065 projector on page 39. However, you should
also read the user's manual that came with your projector for full details on use, care and cleaning.
