Installing Smart Board Software - SMART Board In-WallRear Projection Installation Manual

The 2865 and 2965 both come with the above items and also include:
• the mirror stand
• a box containing the NEC MT1065 projector (with custom short-throw lens), an M3 hex key, a
7/16" wrench, two 9/16" combination wrenches, a user's manual, a remote control and cable,
batteries, software, an RGB cable, and a power cable
To remove the mirror stand from the pallet
1. Remove the two wing nuts on the back brackets that hold the unit to the pallet.
2. Remove the bolts that hold the brackets to each corner of the pallet. To do this, use one of the
two 9/16" combination wrenches that you'll find on the right side of the mirror stand with the
other hardware.
3. Roll the mirror stand down the pallet ramps.

Installing SMART Board Software

Before you install and connect your interactive whiteboard, you need to install SMART Board
software.
SMART Board software contains the tools you need to control any computer application and write
over it. For complete details on this software, refer to the SMART Board Software User's Guide
that came with your unit or the SMART Board software online Help.
CAUTION
Your interactive whiteboard comes with SMART Board software on a CD.
To install SMART Board software
• Insert the SMART Board software CD into your CD drive.
• Follow the on-screen instructions.
If the installation program doesn't start automatically, navigate to the installation folder for
SMART Board software on the CD, double-click the setup.exe file, and follow the on-screen
instructions.
4
Don't connect the SMART USB adapter cable to the computer until after you've
installed SMART Board software.
If you do this by accident, the Found New Hardware wizard appears. Click the
Cancel button in the wizard, and then unplug the SMART USB adapter cable from
the computer. Next, install SMART Board software (version 8.1.3 or later), and then
reconnect the cable.
Preparing to Install Your Interactive Whiteboard
