To adjust the legs, you'll need a 1/2" (1.3 cm) flat or adjustable wrench, or you can use the 9/16"
wrench that comes with the mirror stand. You'll also need two 15/16" flat or adjustable wrenches
for the leveling process.
To install the mirror stand
1. Wheel the mirror stand into the projection room and remove the cross braces from the screen
opening.
2. Remove the strap at the front of the mirror stand. You'll have to adjust the mirror when you set
up the projector (page 32).
3. If you want the computer in the projection room, slide it into place, as shown below.
NOTE: For ease of use, ensure you can access the computer's power switch and drives.
Installing Your Interactive Whiteboard
Remove this strap
17
