applied to J1. This function is useful for connecting power supplies in a "Daisy-chain" (refer to
Section 5.16). The SO control can also be used to reset the OVP and Fold Protection (refer to
Section 5.3 and 5.5 for details).
When the unit is shut-off by a J1 signal, the VOLTAGE display will show "SO" to indicate the unit
state. J1 contact 15 is the SO signal input and contacts 2 and 3, IF_COM, are the signal return
(connected internally). Contacts 2, 3 and 15 are optically isolated from the power supply output.
The SO control logic can be selected by the rear panel SW1 Setup switch. Refer to Table 5-2 for
SW1 setting and SO Control Logic.
SW1-5 setting
Down (default)
Up
5.8 ENABLE/DISABLE CONTROL VIA REAR PANEL J1 CONNECTOR
Contacts 1 and 14 of J1 (Fig.4-2, item 5) serve as Output Enable/Disable terminals by switch or
relay. This function is Enabled or Disabled by the SW1 Setup switch position 9. Refer to Table 5-
3 for Enable/Disable function and SW1 setting.
SW1-9 setting Enable/Disable Inputs
Down (Default)
Safe Start mode-If the Enable/Disable fault condition clears when units in safe start mode recov-
ery is by pressing OUT button or by sending an 'OUT 1' serial command. Auto Restart mode-
The output will return back ON automatically when the Enable/Disable fault conditions clears.

5.9 CV/CC SIGNAL

CV/CC signal indicates the operating mode of the power supply, Constant Voltage or Constant
Current. The CV/CC signal is an open collector output with a 30V parallel zener, at J1-13, refer-
enced to the COM potential at J1-12 (connected internally to the negative sense potential). When
the power supply operates in Constant Voltage mode, CV/CC output is open. When the power
supply operates in Constant Current mode, the CV/CC signal output is low (0-0.6), with maximum
10mA sink current.
Do not connect the CV/CC signal to a voltage source higher than 30VDC. Always
connect the CV/CC signal to voltage source with a series resistor to limit the sink
current to less than 10mA.
5.10
SO signal level
J1-2(3), 15
2-15V or Open
0-0.6V or Short
2-15V or Open
0-0.6V or Short
Table 5-2: SO logic selection
Open or Short
Open
To prevent possible damage to the unit, do not connect any of the
Enable/Disable inputs to the positive or negative output potential.
Short
Table 5-3: Enable/Disable function and SW1 setting
