23 AST?
24 SAV
25 RCL
26 MODE?
27 MS?
NOTES:
1. In Advanced parallel mode (refer to Sec. 5.15.2), "n" is the total system current.
2. In Advanced parallel mode, "MC?" returns the Master unit current multiplied by the number of
slave units +1.

7.9 GLOBAL OUTPUT COMMANDS

7.9.1 GENERAL

All supplies, even if not the currently addressed supply, receiving a global command will
execute the command. No response to the PC issuing the command will be returned to
the PC. The PC issuing the command will be responsible to delay and any other commu-
nications until the command is execute. 200 Ms minimum is the suggested delay.
If the command contains an error, out of range values for example, no error report will be
sent to the issuing PC.
Table 7-3
GRST Reset. Brings the power supply to a safe and known state:
Output voltage: 0V, output current: 0A, OUT: Off, Remote: RMT 1,
AST: Off
The conditional register (FLT and STAT) are updated. Other registers are not
changed.
Non-Latching faults (FB, OVP, SO) are cleared, OUT fault stays
GPV n Sets the output voltage value in volts. The range of voltage values is shown in
Table 7-5. 'n' may be up to 12 char plus dec. pt
GPC n Program the output current value in amperes. The range of current values is
shown in Table 7-6. 'n' may be up to 12 char plus dec. pt
Turns the output to ON or OFF:
GOUT
"OUT 1/ON" = turn on
"OUT 0/OFF" = turnoff, clears CV and CC bits in the Status Condition (STAT).
OUT ON will respond with "E07' if the output cannot be turned on because of a
latching fault (OTP< AC, ENA, SO) shutdown.
Save present settings. Same settings as power-down last settings listed in Er-
GSAV
ror!
Reference source not found. Except the address and Baud rate are not saved
Saves to the RAM. These settings are erased when the supply power is
switched off and the new 'last settings' are saved.
GRCL Recall last settings. Settings are from last power-down or from last 'SAV' or
'GSAV' command. Address and Baud rate are not recalled so communication is
not interrupted.
Returns the string auto-restart mode status.
Saves present settings. The settings are the same as power-down last set-
ting. These settings are erased when the supply power is switched Off and
the new "last settings" are saved.
Recalls last settings. Settings are from the last power-down or from the last
"SAV" command.
Returns the power supply operation mode. When the power supply is On
(OUT 1) it will return "CV" or "CC". When the power supply is OFF (OUT 0 or
fault shutdown) it will return "OFF".
Returns the Master/Slave setting. Master: n= 1, 2, 3, or 4 Slave: n=0
OVP: Max,
58
83-507-5002 Rev. A
UVL: 0.
