Position
Output Voltage
SW1-1
remote analog programming
Output Current
SW1-2
remote analog programming
Terminals 12, 22 and 23 of J1 are connected internally to the
Programming Range Select
negative sense (-S) potential of the power supply. Do not
SW1-3
(Remote voltage/resistive)
attempt to bias any of these terminals relative to the nega-
tive sense. Use the Isolated Programming interface option to
Output Voltage and
SW1-4
Current Monitoring Range allow control from a programming source at a different po-
tential relative to the power supply negative.
SW1-5 Shut-Off Logic select
SW1-6 RS232/485 select
Output Voltage
SW1-7
Resistive Programming
Output Current
SW1-8
Resistive Programming
SW1-9 Enable/Disable control
4.4.2 Resetting the SW1 switch
Before making any changes to the SW1 switch setting, disable the power supply output by
pressing the front panel OUT button. Ensure that the Output Voltage falls to zero and the
OUT LED is Off. Then use any small flat-bladed screwdriver to change the SW1 switch set-
ting.
4.5 REAR PANEL J1 PROGRAMMING AND MONITORNG CONNECTOR
The J1 Programming and Monitoring connector is a DB25 subminiature connector located on the
power supply rear panel. Refer to Table 4-4 for description of the connector functions. The power
supply default configuration is Local operation, which does not require connections to J1. For re-
mote operation using J1 signals, use the plug provided with power supply (or equivalent type). It
is essential to use a plastic body plug to conform to Safety Agency requirements. If a shield is
required for the J1 wires, connect the shield to a power supply chassis ground screw.

4.5.1 Making J1 connections

-J1 Connector type: AMP, P/N:747461-3
-J1 plug description: AMP, P/N:745211-2
-Wire dimension range: AWG26-22
-Manual Pistol grip tool:
-Insertion/Extraction tool: AMP, 91232-1
Before making any connection, turn the AC on/Off switch to the Off position and wait until the
front panel display has turned Off.
Function
Handle:AMP, P/N:58074-1
Head:AMP, P/N:58063-2
83-507-5002 Rev. A
DOWN (Factory default)
Output Voltage
programmed by
Front Panel
Output Current
CAUTION
programmed by Front
Panel
0-5V/(0-5Kohm)
0-5V
Off: Low (0-0.6V) or Short
On: High (2-15V) or Open
RS232 interface
Output Voltage
programmed by Front
Panel
Output Current
programmed by Front
Panel
Rear panel
Enable/Disable control is
not Active
31
UP
Output Voltage
programmed by remote
analog voltage
Output Current
programmed by remote
analog voltage
0-10V/(0-10Kohm)
0-10V
Off: Low (2-15V) or Open
On: High (0-0.6V) or Short
RS485 interface
Output Voltage
programmed by
external resistor
Output Current
programmed by external
resistor
Rear panel
Enable/Disable control
is Active
