7.5 CONNECTING POWER SUPPLIES TO RS232 OR RS485 BUS

7.5.1 Single power supply

1. Select the desired interface RS232 or RS485 using rear panel setup switch SW1-6 (Section 4-
4).
-RS232: DOWN position
-RS485: UP position
2. Connect rear panel IN connector to the controller RS232 or RS485 port using a suitable
shielded cable. Refer to Figures 7-2, 7-3 and 7-4 for available RS232 and RS485 cables.
13
1
Sockets
5
1
Sockets
5
1
Sockets
DB-25 CONNECTOR
PIN NO.
1 SHIELD
TX
2
3 RX
7 SG
Fig.7-2: RS232 cable with DB25 connector (P/N: GEN/232-25)
DB-9 CONNECTOR
PIN NO.
SHIELD
HOUSING
2 RX
3 TX
5
SG
Fig.7-3: RS232 cable with DB9 connector (P/N: GEN/232-9)
DB-9 CONNECTOR
PIN NO.
HOUSING SHIELD
9 TXD
8 TXD
1
SG
5
RXD
4
RXD
Fig.7-4: RS485 cable with DB9 connector (P/N: GEN/485-9)
83-507-5002 Rev. A
L=2m typ.
8 PIN CONNECTOR
NAME PIN NO. NAME
SHIELD
8
RX
7
TX
1
SG
L=2m typ.
8 PIN CONNECTOR
NAME PIN NO.
NAME
HOUSING
SHIELD
7 TX
8
RX
1
SG
L=2m typ.
8 PIN CONNECTOR
NAME PIN NO. NAME
HOUSING SHIELD
-
RXD
6
+
3 RXD
1
SG
-
5
TXD
+ 4
TXD
53
REMARKS
TWISTED
PAIR
REMARKS
TWISTED
PAIR
REMARKS
-
TWISTED
+
PAIR
-
TWISTED
+
PAIR
8
1
8
1
8
1
