Lambda Genesys GENH 750W Technical Manual page 69

Retransmit last
message
Acknowledge
SRQ
Test if MD Mode
is Installed
Supply Initiated
Communications
SRQ
GEN750W models
Table 7-5: Current programming range
Model
GEN6-100
GEN8-90
GEN12.5-60
GEN20-38
GEN30-25
GEN40-19
GEN60-12.5
GEN80-9.5
GEN100-7.5
GEN150-5
GEN300-2.5
GEN600-1.3
NOTE:
The power supply can accept values higher 5% than the table values, however it is not
recommended to program the power supply over the rated values.
Table 7-6: OVP programming range
Model
Rated Output Voltage
(V)
6
110x xxxx
111x xxxx
Byte 1
1010 1010
Byte 2
xxxx xxxx
100x xxxx
Table 7-4. SINGLE BYTE COMMUNICATIONS
Minimum Maximum
(A) (A)
000.00 100.00
00.00 90.00
00.000 60.000
00.000 38.000
00.000 25.000
00.000 19.000
00.000 12.500
0.000 9.500
0.000 7.500
0.000 5.000
0.000 2.500
0.000 1.300
Minimum Maximum
(V) (V)
0.5 7.50
Last message
None
0 or 1
N/A
Table 7-7: UVL programming range
Rated Output Voltage
62
83-507-5002 Rev. A
returned.
Retransmit last response from a
command. x xxxx is the address of
the supply in binary.
Acknowledge SRQ. If retransmis-
sion of SRQ is enabled, it will re-
main enabled for the next SRQ. X
xxxx is the address of the supply in
binary.
Returns a 0 if not installed or a 1 if
installed. A '$' sign followed by a 2
bytes checksum and Carriage Re-
turn is appended to the data. xxxx
xxxx is the address of the supply in
binary.
SRQ from supply when in MD
Mode. X xxxx is the address of the
supply in binary.
Model Minimum
(V)
(V)
6 0
Maximum
(V)
5.70
