A.2 System Packaging
This section describes the features of the system enclosures.
A.2.1 Sun Fire E6900 System
TABLE A-1
TABLE A-1
Front of the system
Up to 6 CPU/Memory boards
2 fan trays
2 to 6 power supplies
Up to 2 System Controller boards
FIGURE A-1
A-2 Sun Fire E6900/E4900 Systems Service Manual • May 2006
lists the parts of the system in the front view and rear view.
Sun Fire E6900 System Components
shows the front and rear views of the Sun Fire E6900 system.
Rear of the System
Up to 4 I/O assemblies
Up to 4 Repeater boards
2 fan trays
