Sun Fire
Version 2 (Enhanced Memory)
Installation Guide
Sun Fire E6900/E4900 Systems
Sun Fire 6800/4800 Systems
Version 2 of the Sun Fire™ System Controller board has increased capacities of
flash memory, dynamic memory, and non-volatile memory.
Note – Do not mix old and new versions of the System Controller (SC) board
in the same system. If a newer version of SC board fails over to an older
version of SC board, the larger quantity of data on the failed SC board can
overload the older version SC board, causing SC software features to terminate
unexpectedly.
Caution – The chassis AC power cord(s) must remain connected to
ensure a proper ground.
Caution – To avoid damaging internal circuits, do not disconnect or
connect any cable while the power is applied to the system.
Caution – The SC board and its modules have surface-mount
components that can be broken by flexing the board.
System Controller Board,
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sun Microsystems Sun Fire E6900
Summary of Contents for Sun Microsystems Sun Fire E6900
- Page 1 Sun Fire System Controller Board, Version 2 (Enhanced Memory) Installation Guide Sun Fire E6900/E4900 Systems Sun Fire 6800/4800 Systems Version 2 of the Sun Fire™ System Controller board has increased capacities of flash memory, dynamic memory, and non-volatile memory. Note – Do not mix old and new versions of the System Controller (SC) board in the same system.
- Page 2 Location of the System Controller Boards System Slot Numbers Slot Location Sun Fire™ E6900 system SSC0 (Master) and SSC1 Front—bottom and top (Redundant controller) Sun Fire™ E4900 system SSC0 (Master) and SSC1 Rear—bottom and top (Redundant controller) Sun Fire™ 6800 system SSC0 (Master) and SSC1 Front—bottom and top (Redundant controller)
- Page 3 Hot-Plug Installations The procedures on the following pages include shutting down the system. However, it is possible to hot-plug the System Controller (SC) board if: You are adding a spare SC board to a system that is currently configured with only one SC board. You are replacing one SC board in a dual SC board system.
- Page 4 6. Open the board ejector levers. Ejector levers Captive fastener 7. Align the board and slide it into the card cage slot. Caution – DO NOT FORCE any board into a slot; this can cause damage to the board and system. The board should insert and seat smoothly.
- Page 5 8. Simultaneously push inward on both board ejector levers to seat the board. 9. Tighten the captive screws by using a Phillips No. 2 screwdriver. 10. Connect the proper cable to the board front panel. 11. Power on the system. Removing a System Controller Board 1.
- Page 6 Sun suppliers. Portions may be derived from Berkeley BSD systems, licensed from U. of CA. Sun, Sun Microsystems, the Sun logo, Sun Fire, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and in other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
