Sun Fire
4800 Systems PCI I/O Assembly
Installation Guide
All systems: If PCI I/O assemblies are to be mixed with CompactPCI I/O
assemblies, install the CompactPCI I/O assemblies only in IB8 or IB9 for
cooling purposes.
Sun Fire™ E6900/6800 systems only: When you install PCI I/O assemblies,
you can install them in either the top or bottom I/O locations. Populate the
I/O assemblies from right to left.

Location of I/O Assemblies

System
Sun Fire E6900/6800 System
Sun Fire E4900/4800 System

Installing a PCI I/O Assembly

Note – The PCI I/O assembly can be inserted into a powered-on system.
However, the assembly will not be recognized by the system until the domain
has been dynamically reconfigured to include the assembly, or re-initialized
and rebooted. Refer to the system administration manual for your product for
complete procedures for initializing a domain. Refer to the dynamic
reconfiguration manual for your product for complete DR procedures.
1. Place a grounded ESD mat close to the system.
2. Wear an ESD strap and connect it to the system.
E6900/E4900/6800/4810/
Slot Numbers
IB6, IB7, IB8, and IB9
IB6, IB8
Slot Location
Rear—bottom right and
left, top right and left
Rear—bottom and top

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fire E6900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sun Microsystems Fire E6900

  • Page 1 I/O locations. Populate the I/O assemblies from right to left. Location of I/O Assemblies System Slot Numbers Slot Location Sun Fire E6900/6800 System IB6, IB7, IB8, and IB9 Rear—bottom right and left, top right and left Sun Fire E4900/4800 System IB6, IB8 Rear—bottom and top...
  • Page 2 Caution – You must install the I/O assembly within one minute of removing the filler panel to prevent overheating. 3. Remove the filler panel from the front of the I/O assembly location and store it for possible future use. 4. Line up the I/O assembly with the I/O assembly opening. Captive screws (4) Ejector lever...
  • Page 3 Note – After reconfiguration, the Activated LED should be on (lit). Removing a PCI I/O Assembly Caution – Remove an assembly from a powered-on system only after the Solaris Operating Environment dynamic reconfiguration (DR) software has disabled that assembly. Refer to the dynamic reconfiguration manual for your product.
  • Page 4 Sun suppliers. Portions may be derived from Berkeley BSD systems, licensed from U. of CA. Sun, Sun Microsystems, the Sun logo, Sun Fire, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and in other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
