6 The PFRemote Control Tool

6.4 Graphical User Interface (GUI)

PFRemote consists of a main window (Fig. 6.3) and a configuration dialog. In the main window,
the camera port can be opened or closed, and log messages are displayed at the bottom. The
configuration dialog appears as a sub window as soon as a camera port was opened
successfully. In the sub window of PFRemote the user can configure the camera properties.
The following sections describe the general structure of PFRemote.

6.4.1 Port Browser

On start, PFRemote displays a list of available communication ports in the main window.
Figure 6.3: PFRemote main window with PortBrowser and log messages
To open a camera on a specific port double click on the port name (e.g. USB). Alternatively
right click on the port name and choose Open & Configure.... The port is then queried for a
compatible Photonfocus camera.
In the PFRemote main window, there are two menus with the following entries available:
File Menu
Clear Log: Clears the log file buffer
Quit: Exit the program
Help Menu
About: Copyright notice and version information
Help F1: Invoke the online help (PFRemote documentation)
