Correcting Uneven Print Quality; Unpacking The Printer - Intermec EasyCoder 3400 Getting Started Manual

Correcting Uneven Print Quality

You may experience problems in print quality (ribbon wrinkling or light print on one side of your
label) if the printhead is not making even contact with the label stock. You need a straight-slot
screwdriver to turn the bias adjust screw.
Note: To achieve the best print quality, adjust the bias adjust screw each time you use media of a different
width.
1
3440G.006
Remove the media cover.
3
A
B
3440G.032
To compensate for uneven print quality, turn the bias
adjust screw as shown.
A If printing is light on right side of label, turn the
bias adjust screw counterclockwise.
B If printing is light on the left side of label, turn
the bias adjust screw clockwise.
24
2
Int erm
ec
3440G.043
Locate the bias screw.
4
3440G.022
Replace the media cover.

Unpacking the Printer

Remove the accessories, packing material, and the printer from the shipping container. Save the
shipping container and packing materials in case you need to move or ship your printer.
Verify the contents of the shipping container against the list below:
1
4
2
3
1 Intermec printer
2 AC power cord
3 PrintSet installation software disk
4 Ribbon core
5 Bar Code Label Printer Getting Started Guide
6 Media support (not shipped with 3600 printer)
7 Media envelope
Note: Make sure you remove all packing material from the printer before you proceed.
7
6
5
3440G.001
