OPTION
General SMS Configuration
SMS
Messages Per Page (10-50)
Encoding Scheme
SMS Forwarding Setup
Forwarding
Redirect to Mobile
TCP server IP address
TCP Port
UDP server IP address
UDP Port
SMS Forwarding Setup
Incoming text messages can be redirected to another mobile device and/or a TCP/UDP message server.
Redirect to Mobile
You can forward incoming text messages to a different destination number. This destination number can be another mobile phone
or a 3G router phone number.
For Example:
If someone sends a text message and Redirect to mobile is set to "+61412345678", the text message is stored on the router and
forwarded to "+61412345678" at the same time.
To disable redirection to a mobile, clear the Redirect to mobile field and click the Save button.
Redirect to TCP / UDP address
You can also forward incoming text messages to a TCP/UDP based destination. The TCP or UDP server can be any kind of public
or private server if the server accepts incoming text-based messages.
The TCP/UDP address can be an IP address or domain name. The port number range is from 1 to 65535. Please refer to your
TCP/UDP based SMS server configuration for which port to use.
For Example:
If someone sends a text message and TCP address is set to "192.168.20.3" and TCP port is set to "2002", this text message is
stored in the router and forwarded to "192.168.20.3" on port "2002" at the same time.
To disable redirection to a TCP or UDP address, clear the TCP address and UDP address fields and click the Save button.
www.netcommwireless.com
Toggles the SMS functionality of the router on and off.
The number of SMS messages to display per page. Must be a value between 10 and 50.
The encoding method used for outbound SMS messages. GSM 7-bit mode permits up to 160
characters per message but drops to 50 characters if the message includes special characters.
UCS-2 mode allows the sending of Unicode characters and permits a message to be up to 50
characters in length.
Toggles the SMS forwarding function of the router on and off.
Enter a mobile number as the destination for forwarded SMS messages.
Enter an IP address or domain name as the destination for forwarded SMS messages using
TCP.
The TCP port on which to connect to the remote destination.
Enter an IP address or domain name as the destination for forwarded SMS messages using
UDP.
The UDP port on which to connect to the remote destination.
Table 2 - SMS Setup Settings
DEFINITION
M2M CDMA Router – SMS Tools User Guide
5
