- Page 1 Vodafone MachineLink 3G TR-069 Whitepaper...
- Page 2 Copyright© 2013 Vodafone Group Plc. All rights reserved. The information contained herein is proprietary to NetComm Wireless and Vodafone. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without prior written consent of NetComm Wireless and Vodafone.
-
Page 3: Table Of Contents
Establishing a connection between a MachineLink 3G Router and Auto Configuration Server ..........................5 TR-069 ACS Server Configuration ..................................................6 TR-069 CPE Configuration ....................................................9 MachineLink 3G Remote Firmware Upgrade/Downgrade Using TR-069 ..................................11 Triggering a connection request via SMS ..............................................15 vodafone.netcommwireless.com... -
Page 4: Introduction
Factory Reset: restore CPE to factory default settings from ACS Server In this white paper, for the purpose of demonstrating how to perform a device firmware upgrade via TR-069, a particular ACS was chosen for taking screenshots. The exact procedures and steps may vary depending on the type of ACS used by the user. For privacy reasons, the login credentials to the management URL of the ACS Server in this white paper has been replaced with http://xxx.xxx.xxx/management/... -
Page 5: Tr-069 Remote Cpe Management Connection Diagram
You have the ACS management URL, administrator user name and password for remote management The MachineLink 3G Router TR-069 device product class name and serial number (SN) is registered in the ACS You have the MachineLink 3G Router ACS CPE connection URL, ACS user name and password ... -
Page 6: Tr-069 Acs Server Configuration
Figure 1: Add Device Type link When creating a device model on the ACS, the OUI and the product class need to match the settings shown in Figure 3 below. Figure 2: Vodafone MachineLink 3G product class name Vodafone MachineLink 3G – TR-069 Whitepaper vodafone.netcommwireless.com... - Page 7 Add the Device on the ACS server Navigate to Home > Manage Devices > Add Device and fill in the add device form, then click Manage Devices. Figure 3: Register TR-069 CPE serial number on ACS Click the Add Device link.
- Page 8 To add multiple devices at once: Click Import Device(s) Click the Browse button and open a CSV file which is formatted as illustrated below: Vodafone MachineLink 3G – TR-069 Whitepaper vodafone.netcommwireless.com...
-
Page 9: Tr-069 Cpe Configuration
By default, the Vodafone MachineLink 3G Router is not pre-configured with active TR-069 client settings and the TR-069 feature is disabled. To test the TR-069 features, you need to manually login via the router’s Ethernet interface to enable the TR-069 feature and configure it with the relevant TR-069 client settings. - Page 10 The device inform message will contain the device’s current WAN IP address. This is viewable by clicking on the Device Data tab. Figure 8: Viewing the device data tab The TR-069 ACS Server and TR-069 M2M Router CPE connection has now been established. You may now start to perform a device firmware upgrade remotely via TR-069.
-
Page 11: Machinelink 3G Remote Firmware Upgrade/Downgrade Using Tr-069
MachineLink 3G Remote Firmware Upgrade/Downgrade Using TR-069 Preparing the device firmware Step 1 - Upload the device firmware to an external FTP/HTTP Server. In this example, the following firmware file links are used: http://www.xxxxx.xxxxxxx.xxxxxxxxx.xxx/vdf_nwl10_1.10.16.1.cdi for main system image ... - Page 12 Figure 11: Create firmware link for MachineLink 3G 1.10.16.1 main system image Once the two firmware file links are created, they will be displayed in the Home > Manage Download summary page on the ACS server. Vodafone MachineLink 3G – TR-069 Whitepaper vodafone.netcommwireless.com...
- Page 13 Queuing Device Firmware ‘Download’ To perform firmware upgrades or downgrades on the router via TR-069, navigate to the ACS server’s management URL: Home > Manage Devices, and select the serial number of the device for which to perform a firmware upgrade or downgrade.
- Page 14 It may take up to 10 minutes to complete the device firmware upgrade task remotely, depending on the 3G connection speed and the distance between the TR-069 CPEs and the TR-069 Server. When the upgrade is complete, navigate to the Device Data tab to confirm the firmware version has changed.
-
Page 15: Triggering A Connection Request Via Sms
Figure 15: Confirming the firmware version has changed Remote CPE firmware upgrade via TR-069 is complete. Triggering a connection request via SMS If the MachineLink 3G does not have a publicly routable IP address, a connection request may be triggered by sending an SMS to the router.
