Chapter 12______________________________________Zaxcom Digital Wireless System User's Manual
ATTACK: ([SLOWEST] / [SLOW] / [NORMAL] / [FAST] / [FASTEST])
CMP RATIO: ________
(value range: 1.0:1 to 5.0:1, step: .1)
CMP THRESH: ________
(value range: 0 to -96 dB, step: 1)
CMP KNEE: ________
(value range: 0 to 20 dB, step: 1)
EXP RATIO: ________
(value range: 1:1.00 to 1:4.00, step: .01)
EXP THRESH: ________
(value range: 0 to -96 dB, step: 1)
REDUCE: ________
(value range: 0 to -36 dB, step: 1)
GAIN: ________
(value range: 0 to 30 dB, step: 1)
xvii. ADC: ________ (ADC Location page)
[INTERNAL] / [EXTERNAL])
xviii. BATTERY TYPE: ________ (Battery Type page)
([LITHIUM] / [ALKALINE] / [NIMH])
xix. RECORD MODE: ________ (Recording Mode page)
([LOOP RECORD] / [NON-LOOP RECORD])
xx. TX POWER: ______ (Audio Transmitter Power page)
([10MW] / [25MW] / [50MW] / [100MW])
xxi. BOOT UP IN: ________ (Boot Up Mode page)
([NORMAL] / [STANDBY])
xxii. MUTE SWITCH: ________ (Mute Switch Enable page)
([0 - DISABLED] / [1 – ENABLED POSITIVE] / [0 – ENABLED NEGATIVE])
xxiii. LR SWITCH MODE: ________ (LR Switch Mode page)
([OFF] / [ON: UP KEY] / [ON: MENU KEY]/ [ON: DOWN KEY]/ [(ALL KEYS])
xxiv. NAME: ______________________ (Transmitter Name page)
(max: 8 chars, char = 0 to 9, space, A to Z)
90
SLOW
3.0:1
-20dB
0dB
1:1.10
-40dB
-12dB
0dB
