Chapter 1_______________________________________Zaxcom Digital Wireless System User's Manual

Microphones

Compatible Lavs

Use one of the following microphone models:
Additional microphones will be added to this list after a review of their 3.3v power performance and RF
interference susceptibility has been completed.

Compatible Stick Mics

Use one of the following microphone models:
Additional microphones will be added to this list after a review of their RF interference susceptibility has been
completed.

General

The TRX900 ( /AA) has an unbalanced microphone input accessed through a 3-pin micro-LEMO connector. You
can use an unbalanced dynamic microphone or a powered lavaliere. It is recommended that you use 3-wire
lavalieres with separate pins for ground, audio and power.
When using a line-level input, an inline pad is required on the standard dynamic microphone input cable (XLR-3 to
3-pin micro-LEMO).
When using a phantom powered microphone with the TRX900 ( /AA), you must use an external 48 VDC power
supply. The TRX700 and TRX992 are the only Zaxcom transmitters that include a 48 VDC phantom power
supply.
NOTE: Once upon a time, the Denecke 48V power supply could damage the now discontinued Goldline
transmitter's preamp. This is NOT the case with the TRX900 ( /AA).
Brand Model
Countryman B6
Countryman E6 omni
Countryman EMW
DPA 4063-BMZ
Sanken COS-11D
Sennheiser MKE-2 Platinum
Sennheiser MKE-2 Gold
Shure WL50
Sony ECM77
Tram TR-50
Voice Tech. VT401HS
Voice Tech VT506
Voice Tech. VT910

Table 1-2 Compatible Lavalier Microphones

Brand Model
Schoeps CMC6MK41
Sennheiser MKH 40
Sennheiser MKH 50
Sennheiser MKH 60
Sennheiser MKH 816

Table 1-3 Compatible Stick Microphones

Voltage
1.5
1.5 Specify for use with Zaxcom
3 Use only the Zaxcom 3.3 V model
3
New model – YES.
Older models – NO
5
Voltage
Older models may pickup some RFI
12
Notes
Notes
