Zaxcom Digital Wireless System User's Manual_______________________________________Chapter 1

Menu System

The user interface for each unit consists of a Liquid Crystal Display with 3 keys, as follows:
• MENU
• INC (up arrow)
• DEC (down arrow) – Decrement the current parameter selected by the MENU key.
Each menu has several pages allowing you to change configuration settings. All of these settings are stored in Flash
ROM immediately after making the change.

Media

Some of the units read from and/or record to a MiniSD card, which is inserted into the MiniSD media slot. All of
the transmitters use a MiniSD card to update the unit's firmware. To be safe, you must use approved media:
SanDisk & Transcend 4GB SDHC MiniSD
ALL Dane-Elec
SanDisk 2GB MiniSD (retail packaging)
SanDisk 2GB MiniSD (bulk packaging)
ALL SanDisk MicroSD (with MiniSD adapter)
ALL SanDisk Ultra
ALL SanDisk Ultra II
Transcend 2GB (x80) MiniSD
ALL Transcend (x45)
Transcend 4GB MiniSD
Any brand that prints the info on a sticker applied to the chip
IMPORTANT: To use any 4GB card, V5.53 or greater is required
If unapproved media is used, it can become jammed in the MiniSD socket and damage it.
CAUTION: Damage resulting from using unapproved media is not covered by the warranty.
Do not use SanDisk Ultra II cards. Formatting one of them may make it unusable.
– Menu page/function select: press once to move to the next menu page.
– Increment the current parameter selected by the MENU key.

Figure 1-1 TRX900 Front View

Media

Table 1-1 Approved vs. Unapproved Media

11
Manufacturer's ID Approved?
SDSDM-2048-A10M
SDSDM-2048, Bulk
TS2GSDM80
TS4GSDM80
YES
NO
YES
YES
YES
NO
NO
YES
NO
YES
NO
