Zaxcom Digital Wireless System User's Manual_______________________________________Chapter 9

TRX992 Specifications

Transmitter
RF Power Output
RF Modulation
RF Frequency Range
RF Frequency Step
RF Bandwidth
Channel Separation
Antenna Connector
Emission Designator
FCC Part
Transmitter Audio
Dynamic Range
Distortion
Frequency Response
Highpass Filter
System Group Delay
Mic Power
Mic Connector
Input Range
Impedance
ADC Bit-depth
ADC Sampling-Rate
Recording
Media
File Format
Recording Time
Timecode Frame-rates
Timecode Type
IFB Receiver
RF Frequency Range
RF Frequency Step
RF Bandwidth
Channel Separation
Sensitivity
DAC Bit-depth
DAC Rate
Frequency Response
Output Impedance
Physical
Weight
Dimensions (H x W x D)
External Power
Internal Power
Display
10 / 25 / 50 / 100 mW – Software selectable
proprietary method
518.0 to 872.0 MHz (blocks are 24 to 36 MHz)
100 KHz
US Setting:
200 KHz
Euro Setting: 125 KHz
500 KHz (700 KHz recommended)
50-ohm SMA female
180 KV2E
74.861
106 dB
0.001%
Mode 0:
20 Hz to 16 kHz
T&M Model: 0.2 Hz to 16 kHz
Off or 30 to 220 Hz, step: 10 (6 dB per octave)
US Mono mode: 3.6 ms
Euro mode:
6 ms
Stereo mode:
6 ms
48 VDC Phantom, balanced, 10 mA max
XLR-3F
Line-level: -10 to +4 dBu
Mic-level: -60 to -30 dBu
Line-level:
6.2 k ohms
Mic-level:
4.6 k ohms
24 bits
48 kHz
MiniSD card (Flash memory)
.ZAX
24 hours (with a 4 GB card)
23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF
SMPTE
2.403 to 2.475 GHz
0.001 GHz
1 MHz Digital Spread Spectrum
2 MHz
-96 dBm
24 bit
48 kHz
20 Hz to 12 kHz
8-ohm minimum
13.2 oz (374 grams) with battery
5,5" x 2.9" x 1.1" (140 mm x 74 mm x 28 mm)
NA
up to 6 hours (one VPX)
Graphics LCD
73
