Chapter 6_______________________________________Zaxcom Digital Wireless System User's Manual

IFB100 Standard Menu

Pacifier page

2.403
2.403
Page purpose:
• Transmitter frequency,
• Audio level meter,
• Status of the IFB100 transport remote control.
NOTE: For diagnostic purposes, you can press the INC or DEC key to read the Motherboard supply voltage.

Remotely Starting and Stopping the Transmitter Recorder

While in this page, pressing the INC or DEC key sends a Record or Stop command to all TRX9xx/ZFR1xx units
in the same group as the IFB100.
When setting the IFB input audio level, normal conversation should be around -20 dB.

Remote Audio Gain Change page

REMOTE GAIN
GROUP01 UNIT=ALL
Page purpose:
Pressing INC displays "+ +" and transmits a command to increase the gain setting, pressing DEC displays "– –"
and transmits a command to decrease the gain setting. Monitor the audio coming from the TRX9xx unit being
adjusted to verify the gain setting change. The Remote Unit ID page can be set to ALL or a specific unit.
NOTE: If the TRX9xx is not in range of the IFB or is on the fringe of coverage, the gain control command may
have to be repeated.
IMPORTANT: Each time gain is increased or decreased, the level changes by 2 dB. The change IS noticeable if
it is done while talent is speaking. What until talent has stopped talking before changing the level.

Remote Unit ID page

REMOTE CONTROL
UNIT ID=ALL
Page purpose:
Parameters:

Remote Audio Frequency Change page

REMOTE CH 512.0 *
UNIT ID=1 000
TX CH
UNIT ID = ALL
Page purpose:
Parameters:
selected in
----
STOP
When you power up the unit, this page appears and displays the following information:
This page allows you to adjust the audio gain on the specified remote transmitter(s).
This page sets the unit you control when you use any of the remote control settings.
[ALL] / [value range:
0
WARNING
This page sets the unit you control when you use any of the remote control settings.
[value range: (see Table
TV Channel Minimum page
to , step: ]
200 1
1
1.3), step: . ] The frequency range is based on the frequency range
and TV Channel Maximum
62
page.
