Zaxcom Digital Wireless System User's Manual_______________________________________Chapter 2
The transport control page changes based on whether the transmitter is in Play mode, Stop mode or is displaying
the current timecode information.
Enter the Transport Control page
Repeatedly press the MENU key until the transport status is shown on the left side of the LCD. The current
transport timecode is displayed while in the transport control page.
Stop mode (playback)
Pressing the DEC key places the transmitter in Stop mode. While in Stop mode, the playback pointer can be
moved backward by pressing the DEC key.
Play mode (playback)
Pressing the INC key places the transmitter in Play mode. While in Play mode, the playback pointer can be
moved forward by pressing the INC key.
The current playback timecode is displayed in the transport control page.
Exiting the Transport Control page
Pressing the MENU key returns the transmitter to Record mode at the last recorded location on the media.

Timecode Frame-rate page

TIMECODE 30NDF
GEN
Page purpose:
timecode as it is being recorded.
Parameters:

Earpiece Source page {TRX9xx only}

IFB EARPIECE:
IFB RX AUDIO
Page purpose:
Parameters:
•
IFB MIX ALL
•
IFB RX AUDIO
•
REC/PLAY

Lock page

LOCK 5
LOCKED 00:00:00:0
Page purpose:
This page has a five-second countdown. After the timer expires, the display indicates
Locking the controls prevents accidently changing settings. As a safety feature, while the unit is locked, only the
unlock combination is available.
Press the INC or DEC key to temporarily display the current battery voltage in place of the battery icon.
If you scan past the

Unlocking the transmitter

Simultaneously press the MENU and INC keys. Once it is unlocked, the screen will display the
Powering down the unit will also clear the lock.
00:00:00:00
This page sets the frame-rate used to record audio on the inserted MiniSD card and displays the
[ ] / [ ] / [
23.98 24
This page establishes the source for the audio being monitored during operation.
– the earpiece receives its audio from both the media and the IFB receiver.
– the earpiece receives its audio from the IFB receiver.
– the earpiece receives its audio from the media.
This page enables a lock function to prevent accidentally changing settings.
display to the next menu page, the
LOCK
] / [ ] / [
25 29.97NDF 29.97DF
29
] / [ ] / [
30NDF
LOCKED
will not engage.
LOCK
]
30DF
.
Pacifier page.
