RS232-GPIB Converter
An optional user-supplied RS232-to-IEEE 488 converter can be used with the RS232
connector on the RM meter to access an IEEE 488 parallel interface. The converter, supplied
with the appropriate RS232 cable, is attached to the RS232 connector on the rear panel.
The converter is set up and tested as described in Table 10 and Table 11. To avoid conflict
with other GPIB devices, the GPIB address can be changed.
Left Dip Switch
The settings for the left dip switch are shown in Table 10.
Table 10: Left Dip Switch Settings
Switch
GPIB ADDR
01000
CONFIG
ON
MODE
OFF
Right Dip Switch
The settings for the right dip switch are shown in Table 11.
Table 11: Right Dip Switch Settings
Switch
BAUD RATE
all OFF
DATA FORMAT OFF
OFF
ON
ON
HANDSHAKE
OFF
10112341 Rev 002
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
Setting
address = 2
use large serial buffer, enable
SRQ
device mode
Setting
set baud rate to 2400
odd/even parity
disable parity checking
use 2 stop bits
use 8 bits per character
disable XON/XOFF protocol
RM3 SERIES BACKREFLECTION METER
