6. Terminate the measurement jumper just before the output connector, and hold the
termination point steady (figure 5a for single-mode(except 980nm), and figure 5b for single-
mode(980nm) and multimode).
NOTE
The termination technique is different depending on the type of the RM Meter used :
single-mode (except 980 nm), single-mode (980nm) or multimode.
Please refer to the Termination Techniques section above.
7. Press the Store BR
0
has been stored. The BR
selected wavelength.
8. Remove the termination.

Measuring Backreflection

To measure backreflection and power from a unit after setting up the meter (see the Setting
Up the Meter for Backreflection Measurements section):
1. Clean the output connector of the measurement jumper and the input connector of the
DUT, and mate the two.
2. Press the λ key to select the wavelength at which the measurement is to be made.
3. Terminate the measurement jumper immediately after the DUT, and hold the termination
point steady. The meter displays the backreflection between the two termination points that
is caused by the fiber, all connections, and the DUT. This area is shown within the dashed
line in Figure 6a for single-mode (except 980nm), and in Figure 6b for single-mode
(980nm) and multimode.
4. If necessary, terminate the fiber for BR
backreflection caused by the fiber and all connections before the DUT.
5. Press the Store BR
0
6. If the backreflection setup has been done previously (BR
to delete the currently stored BR
7. Press λ and repeat step 6 to delete the stored BR
8. Release the termination. The meter now displays the backreflection of the DUT only.
9. If a measurement is to be made at a second wavelength, repeat steps 1 through 8.
The small amount of reflections that BR
reflections can cause interference effects that can make the reflections very sensitive to
10112341 Rev 002
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
key. The key lamp lights to indicate that the background backreflection
value is used in the calculation of the DUT backreflection at the
0
0
key. The key lamp lights to indicate that the function is on.
value. The BR
0
represents can be polarization sensitive, and multiple
0
RM3 SERIES BACKREFLECTION METER
again just before the DUT to eliminate the
light is on), press the BR
0
light turns off.
0
value for another wavelength.
0
USER'S MANUAL
button
0
