AV1
EXTERNAL NOISE TEST
SETUP SPEAKERS LEVELS CALIBRATION
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
Opens the SPEAKER LEVEL ADJUST menu, which is used to adjust
output levels while the external noise test is conducted. The exter-
nal noise test requires an external calibration source, such as an
audio calibration disc.
When the external noise test is conducted, the AV1 activates a lis-
tening mode based on the input source that is present. The table in
the next column indicates the listening mode that is activated for
each input source. When a listening mode is activated during the
external noise test, it retains its factory-default settings, ignoring
custom settings that might have been made on the corresponding
listening mode menu. Custom settings will be restored after the
external noise test is complete.
EXTERNAL NOISE TEST
SETUP SPEAKER SETUP
INPUTS CUSTOM SETUP
SPEAKERS THX SETUP
REAR PANEL CONFIG SPEAKER DISTANCES
DISPLAYS LEVELS CALIBRATION
VOLUME CONTROLS
TRIGGER
0.0 dB
LOCK OPTIONS
0.0 dB
M
SUB
0.0 dB 0.0 dB
LEVELS CALIBRATION
INTERNAL NOISE TEST
EXTERNAL NOISE TEST
BASS PEAK LIMITER
R SR RR
0.0 dB 0.0 dB
C
L SL RL
0.0 dB 0.0 dB
2-Channel Dolby Digital
Sources Sources
DOLBY PLII MOVIE DOLBY DIGITAL*
* These listening mode names differ depending on the source, the speaker co figuration
and certain parameter settings.
Setup
SPEAKER LEVEL ADJUST
FRONT LEFT +0.0dB
CENTER
+0.0dB
FRONT RIGHT
+0.0dB
SIDE RIGHT +0.0dB
REAR RIGHT +0.0dB
REAR LEFT +0.0dB
SIDE LEFT +0.0dB
SUBWOOFER +0.0dB
DTS(-ES)
Sources
DTS(-ES)*
3-39
