[DSP UNIT] (IC-F80DT/DS only)
REF ORDER
NO. NO.
R64 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R65
R66 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R67 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R68 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R70 7030008290 S.RES ERJ2GEJ 183 X (18 kΩ)
R71 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R72 7030008290 S.RES ERJ2GEJ 183 X (18 kΩ)
R73 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R74 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R75 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R76 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R77 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R78 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R79 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R80 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R82 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R83 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R85 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
7030005010 S.RES ERJ2GEJ 681 X (680 Ω)
R86
R87 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R88
R89 7030010040 S.RES ERJ2GE-JPW
7030008370 S.RES ERJ2GEJ 561 X (560 Ω)
R90
R91 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R92 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R93 7030010040 S.RES ERJ2GE-JPW
R94 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R95 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R96 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R97 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
C1 4550007070 S.TAN TEESVP 1A 475M8R
C2 4550007070 S.TAN TEESVP 1A 475M8R
C3 4550007070 S.TAN TEESVP 1A 475M8R
C4 4030017420 S.CER ECJ0EC1H470J
C5 4030016930 S.CER ECJ0EB1A104K
C6 4030016930 S.CER ECJ0EB1A104K
C7 4030016930 S.CER ECJ0EB1A104K
C8 4030016930 S.CER ECJ0EB1A104K
C9 4030017420 S.CER ECJ0EC1H470J
C10 4550006250 S.TAN TEESVA 1A 106M8L
C11 4030017460 S.CER ECJ0EB1E102K
C12 4030017460 S.CER ECJ0EB1E102K
C13 4030017460 S.CER ECJ0EB1E102K
C14 4550007030 S.TAN TEESVP 0J 106M8R
C15 4550007030 S.TAN TEESVP 0J 106M8R
C16 4550007030 S.TAN TEESVP 0J 106M8R
C17 4550006250 S.TAN TEESVA 1A 106M8L
C18 4030016930 S.CER ECJ0EB1A104K
C19 4030016930 S.CER ECJ0EB1A104K
C20 4030017420 S.CER ECJ0EC1H470J
C21 4550006250 S.TAN TEESVA 1A 106M8L
C22 4030016930 S.CER ECJ0EB1A104K
C23 4030017680 S.CER ECJ0EC1H820J
C24 4030017730 S.CER ECJ0EB1E471K
C25 4030017420 S.CER ECJ0EC1H470J
C26 4030016930 S.CER ECJ0EB1A104K
C27 4030017590 S.CER ECJ0EC1H070C
C28 4030016930 S.CER ECJ0EB1A104K
C30 4030017450 S.CER ECJ0EB1E271K
C31 4030017420 S.CER ECJ0EC1H470J
C32 4030016930 S.CER ECJ0EB1A104K
C33 4030016790 S.CER ECJ0EB1C103K
C35 4030017420 S.CER ECJ0EC1H470J
C36 4030017420 S.CER ECJ0EC1H470J
C38 4030017420 S.CER ECJ0EC1H470J
C39 4030017760 S.CER ECJ0EB1H222K
C40 4030017420 S.CER ECJ0EC1H470J
C41 4030017420 S.CER ECJ0EC1H470J
C42 4030017420 S.CER ECJ0EC1H470J
C43 4030017460 S.CER ECJ0EB1E102K
C44 4030017420 S.CER ECJ0EC1H470J
C45 4030017420 S.CER ECJ0EC1H470J
C46 4030017420 S.CER ECJ0EC1H470J
C47 4030017460 S.CER ECJ0EB1E102K
C48 4030017460 S.CER ECJ0EB1E102K
C49 4030017420 S.CER ECJ0EC1H470J
C50 4030017420 S.CER ECJ0EC1H470J
C51 4030017420 S.CER ECJ0EC1H470J
C52 4030016930 S.CER ECJ0EB1A104K
C53 4030017460 S.CER ECJ0EB1E102K
C54 4030016930 S.CER ECJ0EB1A104K
C55 4550007030 S.TAN TEESVP 0J 106M8R
C56 4030017460 S.CER ECJ0EB1E102K
C57 4030017460 S.CER ECJ0EB1E102K
C58 4030016930 S.CER ECJ0EB1A104K
C59 4030017460 S.CER ECJ0EB1E102K
C60 4030017760 S.CER ECJ0EB1H222K
C62 4030017460 S.CER ECJ0EB1E102K
C63 4030016930 S.CER ECJ0EB1A104K
[L]=Low band, [H]=High band
DESCRIPTION M.
LOCATION
B 5.3/11.6
T 25.7/27.1
B 7.3/19.2
T 22/27.3
T 20.8/29.1
T 9.1/10.2
T 8.2/10.2
T 7.3/10.2
T 6.4/9.2
T 5.5/9.2
T 9.3/12.4
T 8.4/12.4
T 7.5/12.9
T 6.6/12.7
T 5.7/12
B 20.7/35.9
T 3.5/17.2
B 2.1/38.6
B 4.3/38.8
B 12.1/20.3
T 10.7/18.5
B 9.8/19.8
T 3.3/37.4
T 22/28.9
T 23.4/25.7
T 23.5/24.8
T 22.2/24
T 7.8/19.8
T 17.1/19.6
T 1.6/11.8
T 1.9/18.6
B 1.2/15.3
B 2/27.6
T 23/4.9
B 22.7/1.7
B 1.3/17.3
B 4.6/27.4
T 21.5/7.7
B 23.7/5.6
B 9.1/8
B 23.5/3.3
B 5.9/23.4
B 4.9/35.2
T 24.5/10
B 4.9/21.3
B 2.9/35.6
T 22.4/10.8
B 14.8/9.5
B 16.4/12.7
B 16.4/11.5
T 17.5/9.7
B 11.8/13
B 12.4/16.8
B 13.2/9
T 18.4/9.7
T 20.2/11.3
T 14/14.3
B 14.6/13.9
B 20.9/19.4
T 19.3/14.7
T 4.9/13.2
B 19.6/18.6
T 12.4/14.6
B 3.1/7.2
B 4.3/7.5
B 3/11.3
B 19.6/20.4
B 7.8/9.9
T 12.9/9.3
T 3.2/8.8
B 16.5/39.7
T 7.6/8.7
B 3.9/8.7
T 3.4/6.4
B 18.6/26.9
B 19.4/34.7
T 3.4/5.5
T 2.4/3.7
B 15.1/5.1
B 17.1/19.6
B 19.4/33.3
T 20.2/12.9
T 14.8/15.7
T 18.3/20.9
B 14.8/22.6
T 12.5/17.4
T 21.8/32.1
T 22.1/14.9
B 13.9/22.4
T 19.9/20
[DSP UNIT] (IC-F80DT/DS only)
H/V REF ORDER
NO. NO.
C64 4030017460 S.CER ECJ0EB1E102K
C65 4030016930 S.CER ECJ0EB1A104K
C66 4550007030 S.TAN TEESVP 0J 106M8R
C67 4030017490 S.CER C1608 JB 1A 105K-T
C68 4030017460 S.CER ECJ0EB1E102K
C69 4030017460 S.CER ECJ0EB1E102K
C70 4030017490 S.CER C1608 JB 1A 105K-T
C71 4030017460 S.CER ECJ0EB1E102K
C72 4030016930 S.CER ECJ0EB1A104K
C73 4030016930 S.CER ECJ0EB1A104K
C74 4030017620 S.CER ECJ0EC1H100C
C75 4030016930 S.CER ECJ0EB1A104K
C76 4030017460 S.CER ECJ0EB1E102K
C77 4030017460 S.CER ECJ0EB1E102K
C78 4030017460 S.CER ECJ0EB1E102K
C79 4030017460 S.CER ECJ0EB1E102K
C80 4030017460 S.CER ECJ0EB1E102K
C81 4030017460 S.CER ECJ0EB1E102K
C82 4550007070 S.TAN TEESVP 1A 475M8R
C83 4030016790 S.CER ECJ0EB1C103K
C84 4030016930 S.CER ECJ0EB1A104K
C85 4030016930 S.CER ECJ0EB1A104K
C86 4030017460 S.CER ECJ0EB1E102K
C88 4030017730 S.CER ECJ0EB1E471K
C89 4030017490 S.CER C1608 JB 1A 105K-T
C90 4030017730 S.CER ECJ0EB1E471K
C91 4030017730 S.CER ECJ0EB1E471K
C92 4030016930 S.CER ECJ0EB1A104K
C93 4030017640 S.CER ECJ0EC1H150J
C94 4030016930 S.CER ECJ0EB1A104K
J1 6510018440 S.CNR AXN430C330P
[FUSE BOARD]
REF ORDER
NO. NO.
L1 6200006190 S.COL BLM21PG300SN1D
C1 4030017460 S.CER ECJ0EB1E102K
J1 6910016860 CNR

[VR BOARD]

REF ORDER
NO. NO.
R1 7210003200 VAR
DS1 5040003170 LED
S1 2250000500 ECR
[ANT BOARD]
REF ORDER
NO. NO.
L1 6200008330 S.COL 0.45-1.4-4TL 15N
6200009360 S.COL 0.45-1.4-3TL 11N
C1 4030006980 S.CER C1608 CH 1H 070D-T
4030009520 S.CER C1608 CH 1H 020B-T
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910015860 CNR
J2 6910016780 CNR
W1 8900013740 CBL
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 8
DESCRIPTION M.
T
T
T
T
T
T
T
T
B
T
T
T
B
T
B
T
T
T
T
B
T
T
B
B
B
B
B
T
T
T
T
DESCRIPTION M.
T
T
IMSA-9230B-1-02H12-PT1
DESCRIPTION M.
TP76N937N-16.5F-10KA-2803
UW3804X
TP70TF5164S-20F-2803
DESCRIPTION M.
[L] T
[H] T
[L] T
[H] T
DESCRIPTION M.
IMSA-6277S-02A-G
ANT CONNECTOR-105
OPC-1429
S.=Surface mount
H/V
LOCATION
23/14
18.9/17.6
22.4/12.6
20/17.2
1.2/26.5
1.6/38.1
20.9/37.9
19.2/37.5
24.7/19.3
25.7/38.9
23.3/32.1
24.5/32.6
4.9/18.8
24.8/27.1
9.4/21.8
18.9/38.7
9.3/21.3
10.3/13.3
2.8/21.9
17.4/39.7
4.9/21.5
2.5/23.3
1.2/37.9
1.4/23.1
2.9/21.9
1.5/24.8
4.8/4.9
21.8/30.5
23.3/27.5
22.2/25.6
13.2/4.3
H/V
LOCATION
7.5/6.5
10.5/2.9
H/V
LOCATION
H/V
LOCATION
3.9/10.4
3.9/10.4
2.6/13
2.6/13
H/V
LOCATION
