SECTION 6

[FRONT UNIT]

REF ORDER
NO. NO.
IC1 1110006440 S.IC M62320FP DF5J
IC2 1110006440 S.IC M62320FP DF5J
IC101 1180002400 S.REG S-812C30AMC-C2K-T2
IC201 1110001810 S.IC TA7368F (ER)
IC203 1110005340 S.IC NJM12902V-TE1
IC204 1130004200 S.IC TC4S66F (TE85R)
IC205 1130004200 S.IC TC4S66F (TE85R)
Q1 1590000980 S.TR DTB123EK T146
Q2 1590000980 S.TR DTB123EK T146
Q102 1590001940 S.TR DTC144EE TL
Q103 1590000980 S.TR DTB123EK T146
Q104 1590000980 S.TR DTB123EK T146
Q201 1590002230 S.TR UMG2N TL
Q202 1520000450 S.TR 2SB1132 T100 Q
Q203 1590001190 S.TR XP6501-(TX) AB
Q206 1590002430 S.TR DTA144EE TL
Q207 1590000430 S.TR DTC144EUA T106
Q208 1530002840 S.TR 2SC4116-Y (TE85R)
Q209 1560001330 S.FET RSR025N03
Q210 1560001330 S.FET RSR025N03
D1 1730002530 S.ZEN NNCD6.2G-T1
D101 1160000140 S.DIO DAP222 TL
D102 1160000140 S.DIO DAP222 TL
D201 1790001250 S.DIO MA2S111-(TX)
D202 1790001250 S.DIO MA2S111-(TX)
D203 1790001250 S.DIO MA2S111-(TX)
D204 1790001250 S.DIO MA2S111-(TX)
D205 1790001250 S.DIO MA2S111-(TX)
L1 6200004720 S.COL MLF1608D R10K-T
L2 6200004720 S.COL MLF1608D R10K-T
L3 6200004720 S.COL MLF1608D R10K-T
L4 6200004720 S.COL MLF1608D R10K-T
L5 6200004720 S.COL MLF1608D R10K-T
L6 6200004720 S.COL MLF1608D R10K-T
L7 6200004720 S.COL MLF1608D R10K-T
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R1
7030007280 S.RES ERJ2GEJ 331 X (330 Ω)
R2
R3 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R4
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R5
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R6
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R7
R11 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
7030001090 S.RES MCR50JZHJ 47 Ω (470)
R12
R13 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R15
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R16
R30 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R31 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R32 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R33 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R34 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R35 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R36 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R37 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R38 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R40 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R50 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R51 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030007270 S.RES ERJ2GEJ 151 X (150 Ω)
R101
7030008370 S.RES ERJ2GEJ 561 X (560 Ω)
R102
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R103
R104 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030007250 S.RES ERJ2GEJ 220 X (22 Ω)
R105
7030007250 S.RES ERJ2GEJ 220 X (22 Ω)
R106
R107 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R108 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R109 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R110 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R111 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R112 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R113 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R115 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R116 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R201 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
[L]=Low band, [H]=High band

PARTS LIST

DESCRIPTION M.
LOCATION
B 20.7/73.6
B 20.7/62.5
B 9.4/80.8
B 28.5/47.4
B 8.2/68
B 7.6/75.9
B 34/56.1
B 34.6/94.7
B 34.4/98.3
B 26.2/72.9
B 12.7/76.7
B 28.2/35.7
B 14/55
B 35.4/37.3
B 29.9/42.1
B 14/50.9
B 37.1/96.5
B 41.4/113
B 41.1/109.5
B 41.1/105.4
B 25.2/81.6
B 15.3/47.1
B 15.3/45
B 17.2/49
B 10.9/71.5
B 36.2/54.2
B 12.3/50.9
B 14.9/52.7
B 30.3/87.8
B 28.9/88.5
B 26.3/87.1
B 21.6/89.7
B 25.1/88.1
B 31.2/90.2
B 23.9/86.1
T 34.8/127
T 34.8/126.1
B 36.5/93.5
B 26.1/77
B 26.1/75.8
B 25.7/67
B 25.8/65.1
B 21.3/86.2
B 33.7/83.9
B 27.5/87.1
B 22.8/86.3
B 28.2/85
B 40.7/74.4
B 40.7/75.3
B 40.7/76.2
B 40.5/77.1
B 17.2/89.4
B 18.1/89.3
B 19/89.3
B 19.9/89.3
B 40.7/65.6
B 40.7/72.5
[F80DT/T] only B 16.4/79.1
[F80DS/S] only B 17/80.6
B 12.6/78.9
B 11.1/78.3
B 18.2/33.6
B 15.4/57.1
B 9.1/93.2
B 10/93.2
B 14.1/57.9
B 14.8/60.7
B 15.2/62.5
B 26.6/58.8
B 26.6/59.7
B 26.6/60.6
B 26.6/61.5
B 12.8/94.2
B 40/67.7
B 17.6/55
[FRONT UNIT]
H/V REF ORDER
NO. NO.
R202 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R203 7030003830 S.RES ERJ3GEYJ 185 V (1.8 MΩ)
R204 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R205 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R207 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R208 7030007060 S.RES ERJ2GEJ 684X (680 kΩ)
R209 7030005230 S.RES ERJ2GEJ 334 X (330 kΩ)
R210 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R211 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R212 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R213 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R214 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R215 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R216 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R217 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R219 7030003860 S.RES ERJ3GE JPW V
R221 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R222 7030005080 S.RES ERJ2GEJ 823 X (82 kΩ)
R223 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R224 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R225 7030009140 S.RES ERJ2GEJ 272 X (2.7 kΩ)
R226 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R227 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R228 7030005700 S.RES ERJ2GEJ 274 X (270 kΩ)
R229 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R231 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R232 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030007260 S.RES ERJ2GEJ 330 X (33 Ω)
R235
7030005530 S.RES ERJ2GEJ 100 X (10 Ω)
R236
R237 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R238 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
R239 7030005170 S.RES ERJ2GEJ 474 X (470 kΩ)
R240 7030005170 S.RES ERJ2GEJ 474 X (470 kΩ)
R241 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R242 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R250 7030003860 S.RES ERJ3GE JPW V
R251 7030003860 S.RES ERJ3GE JPW V
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R259
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R260
R261 7030003860 S.RES ERJ3GE JPW V
R262 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R263 7030010040 S.RES ERJ2GE-JPW
R264 7030010040 S.RES ERJ2GE-JPW
R265 7030010040 S.RES ERJ2GE-JPW
R266 7030010040 S.RES ERJ2GE-JPW
R267 7030010040 S.RES ERJ2GE-JPW
R268 7030010040 S.RES ERJ2GE-JPW
R269 7030010040 S.RES ERJ2GE-JPW
R270 7030010040 S.RES ERJ2GE-JPW
R271 7030010040 S.RES ERJ2GE-JPW
R272 7030010040 S.RES ERJ2GE-JPW
R273 7030010040 S.RES ERJ2GE-JPW
R274 7030010040 S.RES ERJ2GE-JPW
R275 7030010040 S.RES ERJ2GE-JPW
R276 7030010040 S.RES ERJ2GE-JPW
R277 7030010040 S.RES ERJ2GE-JPW
R278 7030010040 S.RES ERJ2GE-JPW
C2 4030016790 S.CER ECJ0EB1C103K
C3 4030017460 S.CER ECJ0EB1E102K
C4 4030016930 S.CER ECJ0EB1A104K
C5 4030016930 S.CER ECJ0EB1A104K
C6 4030017460 S.CER ECJ0EB1E102K
C7 4030017460 S.CER ECJ0EB1E102K
C8 4030017430 S.CER ECJ0EC1H101J
C9 4030017430 S.CER ECJ0EC1H101J
C10 4030017430 S.CER ECJ0EC1H101J
C11 4030017460 S.CER ECJ0EB1E102K
C12 4030017430 S.CER ECJ0EC1H101J
C13 4030017430 S.CER ECJ0EC1H101J
C15 4030017430 S.CER ECJ0EC1H101J
C16 4030016790 S.CER ECJ0EB1C103K
C17 4030009580 S.CER C1608 JB 1H 681K-T
C18 4030009580 S.CER C1608 JB 1H 681K-T
C19 4030009580 S.CER C1608 JB 1H 681K-T
C101 4550006300 S.TAN
C102 4030016930 S.CER ECJ0EB1A104K
C103 4030016930 S.CER ECJ0EB1A104K
C104 4030017420 S.CER ECJ0EC1H470J
C105 4550006150 S.TAN
C106 4550006620 S.TAN
C107 4030016790 S.CER ECJ0EB1C103K
C108 4030009580 S.CER C1608 JB 1H 681K-T
C109 4030016930 S.CER ECJ0EB1A104K
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
DESCRIPTION M.
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
ECST1AY475R B
B
B
B
ECST1CY105R B
ECST0JY226R B
B
B
B
S.=Surface mount
H/V
LOCATION
16.3/54.2
26.8/71.1
15.5/48.9
14.5/49.2
11.8/63.6
12.6/69.7
13.8/68.6
13.8/66.8
13.8/69.5
Mar-69
31.5/57.4
36.2/56.3
27.2/42.1
13.6/49.2
10.2/64.5
7.3/64.3
6.4/63.2
34.5/51
3/69.9
2.8/67.1
30.2/43.9
27.2/43.9
16.7/51.2
5.1/64.9
9.3/72.6
3/68.1
7.6/72.6
27.6/51.9
27.6/51
5.6/78.2
6/79.4
36.5/99.3
38.5/98.7
36.9/98.4
41.9/114.9
27.2/68.1
40.2/78.8
16.6/87.8
15.7/87.8
41.3/71.5
16.7/53
40.5/46
40.5/40
40.5/34
40.5/28
40.5/22
40.5/15.9
40.5/10
40.5/4
5.4/46
5.4/40
5.4/34
5.5/28
5.5/16
5.5/4
5.5/10
5.5/22
21.3/87.6
17.1/86.6
15.3/75.2
15.2/64.3
15.3/74.3
15.2/63.4
22.7/83.3
19.4/86.3
19/87.8
26.1/84.8
24.2/84.1
41.1/73.4
17.5/87.8
22.2/85.1
26.9/38.1
30.8/36.1
35.5/40.9
13.8/80.6
12.3/82.1
16.4/32.6
41.3/67.6
7.2/90.4
11.6/83.8
10.8/85.4
15.4/43.3
9/91.5
