[MAIN UNIT]
REF ORDER
NO. NO.
R336 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R337 7030010040 S.RES ERJ2GE-JPW
R338 7030005310 S.RES ERJ2GEJ 124 X (120 kΩ)
R339 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R340 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030005010 S.RES ERJ2GEJ 681 X (680 Ω)
R342
R344 7030005230 S.RES ERJ2GEJ 334 X (330 kΩ)
R345 7030005230 S.RES ERJ2GEJ 334 X (330 kΩ)
R346 7030005230 S.RES ERJ2GEJ 334 X (330 kΩ)
R347 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R348 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R349 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R350 7410001140 S.ARY EXB28V104JX
R351 7030008410 S.RES ERJ2GEJ 392 X (3.9 kΩ)
R352 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R353 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R354 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R355 7030005310 S.RES ERJ2GEJ 124 X (120 kΩ)
R356 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R357 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R358 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R359 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R360 7030008290 S.RES ERJ2GEJ 183 X (18 kΩ)
R361 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R362 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R363 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R364 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R365 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R366 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R367 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R368 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R371 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R372 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R373 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R374 7030008300 S.RES ERJ2GEJ 184 X (180 kΩ)
R375 7030005720 S.RES ERJ2GEJ 563 X (56 kΩ)
R376 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R377 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R378 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R379 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R380 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R381 7030008010 S.RES ERJ2GEJ 123 X (12 kΩ)
R382 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R383 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R384 7030008010 S.RES ERJ2GEJ 123 X (12 kΩ)
R385 7030008010 S.RES ERJ2GEJ 123 X (12 kΩ)
R386 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R387 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R388 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R389
R391 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R393 7030005080 S.RES ERJ2GEJ 823 X (82 kΩ)
R394 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R396 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
R397 7030008290 S.RES ERJ2GEJ 183 X (18 kΩ)
7030005530 S.RES ERJ2GEJ 100 X (10 Ω)
R399
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R400
7030009320 S.RES ERJ2GEJ 4R7 X (4.7 Ω)
R401
R402 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R403
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R404
R405 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R406 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R407 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R408 7410001130 S.ARY EXB28V102JX
R409 7410001130 S.ARY EXB28V102JX
R410 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R411 7410001130 S.ARY EXB28V102JX
R412 7410001130 S.ARY EXB28V102JX
R413 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R414 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R415 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R416 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R417 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R418 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R419 7410001140 S.ARY EXB28V104JX
R420 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R421 7410001130 S.ARY EXB28V102JX
R422 7410001130 S.ARY EXB28V102JX
R423 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
R424 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R425 7410001130 S.ARY EXB28V102JX
R426 7410001130 S.ARY EXB28V102JX
R427 7410001130 S.ARY EXB28V102JX
R428 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R429 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R430 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R431 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R432 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R433
R434 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R435
R436 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R437 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
[L]=Low band, [H]=High band
DESCRIPTION M.
LOCATION
T 57.2/17.4
T 35/23.5
T 60.7/15.9
T 58.8/17.4
B 4.6/31
T 76.1/19.3
T 23.8/11.8
T 23.8/13.2
T 20/12.4
T 15.6/14.2
T 17.1/12.1
T 15.8/12.5
T 4.4/9.9
T 67.7/17.9
T 67.6/19.1
T 65.3/20.1
T 63.3/18.1
T 64.8/16.6
B 37.6/35.3
T 20/11.5
T 22.4/12.3
T 22.4/11.4
T 51.8/9.1
T 53.4/9.1
T 52.2/16
T 53/13.9
T 53.2/12.1
T 58.2/7.9
T 51.9/10.8
T 60.7/13.5
T 50.4/12.1
T 61.6/14.7
T 51.3/14.5
T 24.9/18.2
B 25/17.4
B 23.7/17.4
B 23.7/18.3
B 26.8/17.3
T 49.4/21.7
B 23.1/29.8
B 23.1/28.9
B 26.3/35.5
T 47.6/18.1
B 11/37.8
B 26/29.9
B 27/37.9
B 27/25.8
B 26/28.1
B 24.8/27.4
T 49.4/24.4
B 21.7/32.7
B 40.9/20.4
B 40.9/19.5
T 39.9/33.5
B 30.9/25.5
B 20.4/31.4
T 50.4/35.8
T 73/30.6
B 24.8/23
B 23.7/20.1
B 23.7/21
B 10.3/33.2
B 23.7/19.2
B 24.8/26.5
B 7.8/30.1
B 20.6/16.9
B 5.5/31
B 18.6/15.3
B 5.8/28.1
T 6.6/14.4
T 12.3/27
T 12.7/28.2
B 19.3/12.2
B 19.3/13.4
B 3.2/16.9
T 9.8/16.8
B 106.1/43.1
B 5.1/22.5
B 7.8/18
B 7.3/9.2
B 107.9/42.3
B 6.2/20
B 9.9/16.4
B 12.3/14.5
B 95.5/34.1
B 95.8/35.4
B 82.8/40.2
B 83.6/38.9
T 79/14.1
T 77.4/14.1
B 108.8/42.3
B 117/38.6
B 122.2/40.8
T 5.1/7.2
[MAIN UNIT]
H/V REF ORDER
NO. NO.
R438 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R439 7030005700 S.RES ERJ2GEJ 274 X (270 kΩ)
R440 7030010080 S.RES ERJ2RHD 104 X (100 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R441
R442 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R443 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R444 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R445 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R446 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R447 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R448 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R449 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R450 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R451 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R452 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R453 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R454 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R455 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R456 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R457 7030005290 S.RES ERJ2GEJ 682 X (6.8 kΩ)
7030009140 S.RES ERJ2GEJ 272 X (2.7 kΩ)
R460 7030008290 S.RES ERJ2GEJ 183 X (18 kΩ)
R461 7030010040 S.RES ERJ2GE-JPW
R462 7030010040 S.RES ERJ2GE-JPW
R464 7030010040 S.RES ERJ2GE-JPW
R465 7030010040 S.RES ERJ2GE-JPW
R466 7030010040 S.RES ERJ2GE-JPW
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R467
7030004990 S.RES ERJ2GEJ 221 X (220 Ω)
R500
R501 7030010040 S.RES ERJ2GE-JPW
7030009270 S.RES ERJ2GEJ 821 X (820 Ω)
R502
R503 7030010040 S.RES ERJ2GE-JPW
R504 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R505 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R506 7030010040 S.RES ERJ2GE-JPW
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R507
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R508
7030009270 S.RES ERJ2GEJ 821 X (820 Ω)
R509
7030010130 S.RES ERJ2GE 6R8 X (6.8 Ω)
R510
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R511
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R512
7030007270 S.RES ERJ2GEJ 151 X (150 Ω)
R513
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R514
7030005530 S.RES ERJ2GEJ 100 X (10 Ω)
R515
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R516
7030009270 S.RES ERJ2GEJ 821 X (820 Ω)
R517
R518 7030000010 S.RES MCR10EZHJ JPW (000)
R519 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R520
R521 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R525 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R527 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R529 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R530 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030004970 S.RES ERJ2GEJ 470 X (47 Ω)
R532
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R533
R534 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R535 7030008300 S.RES ERJ2GEJ 184 X (180 kΩ)
R536 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
7030005530 S.RES ERJ2GEJ 100 X (10 Ω)
R537
R539 7030008400 S.RES ERJ2GEJ 182 X (1.8 kΩ)
R540 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R541 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R542 7030005170 S.RES ERJ2GEJ 474 X (470 kΩ)
R543 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R545 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R546 7030003670 S.RES ERJ3GEYJ 823 V (82 kΩ)
R548 7030005170 S.RES ERJ2GEJ 474 X (470 kΩ)
R549 7030010040 S.RES ERJ2GE-JPW
R600 7030010040 S.RES ERJ2GE-JPW
R601 7030010040 S.RES ERJ2GE-JPW
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R602
R604 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R605 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R606 7030005290 S.RES ERJ2GEJ 682 X (6.8 kΩ)
R607 7030005030 S.RES ERJ2GEJ 152 X (1.5 kΩ)
R608 7030005030 S.RES ERJ2GEJ 152 X (1.5 kΩ)
R609 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R610
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R611
7030005000 S.RES ERJ2GEJ 471 X (470 Ω)
R612
R613 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R614 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R615 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R616
R617 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R618 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R619 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
7030004980 S.RES ERJ2GEJ 101 X (100 Ω)
R620
R621 7030005100 S.RES ERJ2GEJ 154 X (150 kΩ)
R622 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
7030005530 S.RES ERJ2GEJ 100 X (10 Ω)
R623
R624 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 4
DESCRIPTION M.
LOCATION
T 3.1/8.1
B 120.2/29.2
B 120.2/28.3
T 5.4/36.8
B 7.9/38.1
B 10.8/40.8
B 3.5/26.9
B 3.5/28.7
B 9.3/33.2
B 29.3/23.1
B 24/13.2
B 22.9/13.2
T 22/13.5
T 27.5/22.2
T 26.6/22.2
T 25.6/22.2
T 23.4/22.7
T 24.6/22.2
B 28.2/36.4
[L] B 28.2/37.3
[H] B 28.2/37.3
T 76.2/30.3
B 25.1/6.5
B 32.5/34.7
T 56/17.8
B 69.2/16
B 20.6/12.1
T 72.1/32.5
B 62.3/26.7
T 19.2/13.9
B 65.1/30.1
T 4.8/11.8
B 65.1/28
B 64.2/27.1
T 34.3/35.1
B 65.7/31.9
B 83.1/10.5
B 76.4/23.9
B 75.8/22.5
B 83.1/9.6
B 75.9/16.9
B 76.2/10.1
B 90.8/14
B 92.3/14.4
B 93.5/15.9
B 74.5/22
B 85/5.8
B 46.8/17.1
B 102.2/15.5
B 103.4/15
T 87.1/6.4
T 84.9/5.2
T 89.3/5
T 90.8/8.1
T 96.1/12.4
T 92.5/8.5
T 96.6/9.9
T 97.8/9.1
B 96.2/9.8
B 95/11.1
B 89.4/9.6
T 102/5.1
B 102.7/5.7
B 90.7/6.7
T 105.4/3
B 89/8.4
B 122.7/10.7
T 23/27.9
T 90.8/10.9
T 85.2/28.2
T 85.2/27.3
T 84.4/23.9
T 94.2/30.5
T 95.1/23.4
T 93.9/18.6
T 93.3/30.5
T 94.9/24.6
T 95.1/18.2
T 97.2/30.5
T 97.9/33.7
T 97.6/23.1
B 95.6/19.8
B 94.2/22.5
B 96/24.5
B 94.4/18.7
B 94.4/30.4
B 95.4/30.1
B 93.8/26.7
B 93.2/28
B 92.3/28
[L] B 97.6/19.5
[H] B 97.6/19.5
B 96/18.7
B 102.4/18.7
S.=Surface mount
H/V
