Icom IC-F80DS Service Manual page 28

SECTION 7
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910015860 IMSA-6277S-O2A-G
J2 6910016780 ANT connector 105
SP1 2510001300 036D0801C
W1 8900013740 OPC-1429
W2 8900010960 OPC-1129
MP1 8210021540 2803 S-front panel
8210021800 2803 T-front panel
MP2 8210021490 2803 rear panel
MP8 8610012350 Knob N-327
MP10 8610012200 Knob N-321 (A)
MP17 8010019840 2803 chassis
MP20 8930064750 2803 main seal
MP22 8930064770 2803 release plate
MP25 8930059830 2600 sheet
MP26 8930065270 2803 MIC seal
MP29 8930059800 2600 pet sheet
MP34 8930059360 2600 release button
MP35 8930056540 Spring (AH)
MP39 8930063690 O-ring (BA)
MP41 8930055730 2403 connector seal
MP43 8830001470 VR nut (N)
MP44 8830002430 2803 ANT nut
MP47 8810010480 Screw PH B0 2X6 SUS SSBC
MP49 8810010120 Screw PH B0 2X8 SUS ZK
MP50 8820001320 2795 screw
MP51 8810009510 Screw PH B0 2X4 Ni-Zu (BT)
MP52 8810008970 Screw FH B0 2X3.5 Ni-ZU (BT)
MP53 8810010430 Screw truss M3X5 SUS SSBC
MP55 8930063060 2721 T-rubber
MP56 8850002590 2803 ANT washer
MP57 8810009180 Screw FH BT B0 2X5 Ni-Zu (BT)
[FRONT UNIT]
REF ORDER
NO. NO.
MC201 7700002310 EM-140
MP1 8210021460 2803 refl ector
MP2 8930061120 Shield sponge (AA)
MP3 8930062540 Sponge (HO)
MP5 8930066040 Sponge (IK)
MP6 8930066250 2803 sponge
MP7 8930057931 Shield sponge (M)-1
[MAIN UNIT]
REF ORDER
NO. NO.
MP3 8510016870 2803 VCO cover
MP5 8510017130 2804 PA shield
MP6 8930066240 Sponge (IM)
[DSP UNIT] (IC-F80DT/DS only)
REF ORDER
NO. NO.
MP1 8930059940 Sponge (HF)
[FUSE BOARD]
REF ORDER
NO. NO.
J1 6910016860 9230B-1-02H12-Pt1
MECHANICALPARTS AND DISASSEMBLY
DESCRIPTION
[IC-F80DS/S]
[IC-F80DT/T]
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
[VR BOARD]
REF ORDER
QTY.
NO. NO.
1
R1 7210003200 TP76N937N 16.5F A103-2803
1
DS1 5040003170 UW3804X
1
S1 2250000500 TP70TF5164S 20F-2803
1
1
MP1 8930057690 O ring (AQ)
1 Screw abbreviations
1
B0, BT: Self-tapping PH: Pan head
1
NI-ZU: Nickel-Zinc
1
1
1
[ACCESORIES]
1
1
REF ORDER
1
NO. NO.
1
EP1 Optional product
1
EP2
Optional product
1
2
MP1 Optional product
2 MP2 8210021470 2803 side panel
MP3 8810010430 Screw truss M3X5 SUS SSBC
1
2
1
2
EP1
4
2
10
2
1
1
1
5
QTY.
1
1
2
2
1
1
1
QTY.
1
1
1
QTY.
1
QTY.
1
7 - 1
DESCRIPTION
ZK: Black
DESCRIPTION
FA-SC57U-1
BP-235
MB-94
MP1
EP2
MP2
* Design is depended on versions.
QTY.
1
1
1
2
QTY.
1
1
1
1
1
MP3
