SOFTWARE ADJUSTMENT (Continued)
Select an operation using [↑] / [↓] keys, then set specifi ed value using [←] / [→] keys on the connected computer keyboard
ADJUSTMENT
ADJUSTMENT CONDITION
1 • Preset [Dig Mode]
DIGITAL
DEVIATION*
2 • Operating CH.
[MOD Dig C]
• Set an FM deviation meter as;
HPF
LPF
De- emphasis
Detector
• Transmitting
3 • Operating CH.
[MOD Dig L]
• Transmitting
4 • Operating CH.
[MOD Dig H]
• Transmitting
1 • Preset [Dig Mode]
DIGITAL
DEVIATION*
2 • Operating CH.
[MOD Dig C]
• Transmitting
3 • Operating CH.
[MOD Dig L]
• Transmitting
4 • Operating CH.
[MOD Dig H]
• Transmitting
1 • Operating CH.
CTCSS/DTCS
• No audio applied to the JIG cable.
DEVIATION
• Set an FM deviation meter as;
[CTCSS/DTCS]
HPF
LPF
De- emphasis
Detector
• Transmitting
1 • Operating CH.
2/5 TONE
/DTMF
• No audio applied to the JIG cable.
DEVIATION
• Set an FM deviation meter as;
[S.Tone]
HPF
LPF
De- emphasis
Detector
• Push [P3] while transmitting.
*; [IC-F80DT/DS] only
UNIT
: 7
Top
panel
: CH 9
: OFF
: 20 kHz
: OFF
: (P–P)/2
: CH 10
: CH 11
: 6
Top
panel
: CH 9
: CH 10
: CH 11
: CH 12
Top
panel
: OFF
: 20 kHz
: OFF
: (P–P)/2
: CH 2
Top
panel
: OFF
: 20 kHz
: OFF
: (P–P)/2
5 - 6
MEASUREMENT
OPERATION
Connect an FM deviation meter to
the antenna connector through
an attenuator.
Connect an FM deviation meter to
the antenna connector through
an attenuator.
Connect an FM deviation meter to
the antenna connector through
an attenuator.
Connect an FM deviation meter to
the antenna connector through
an attenuator.
VALUE
±2.80 to ±2.90 kHz
±0.91 to ±1.01 kHz
(Verify)
±0.60 to ±0.70 kHz
±1.50 kHz
