Vr Board - Icom IC-M802 Service Manual

MP8008 (F)
DS8220 (C)
MP8007 (F)
MP8023 (F)
MP8009 (F)
S8801 (S)
RC-25 MP8017 (F)
MP8004 (F) W8001 (F)
MP8006 (F)
W8005 (F)
S8802 (S)
R8901 (V)
MP8016 (F)
MP8020 (F)
J8602 (J)
J8061 (J)
JACK BOARD
MP8022 (F)
J8702 (D)
J8701 (D)
SENSOR
BOARD
S8801 (S)
MP8001 (F)
Unit abbreviations
6 - 3
MP8002 (F)
MP8022 (F)
W8001 (F)
W8005 (F)
MP8201 (D)
DISPLAY
BOARD
VR
BOARD
S8802 (S)
R8901 (V)
MP8005 (F)
(F): FRONT PARTS
(D): DISPLAY BOARD
(J): JACK BOARD
(S): SENSOR BOARD
(V): VR BOARD
(C): CONNECT BOARD
