- Page 1 W-508 & W-510 Fog Machine User Manual Please read and save these instructions. Antari Lighting and Effects Ltd.
-
Page 2: Danger Of Electric Shock
User Manual W-508 & W-510 Fog Machine Congratulations on the purchase of your new ANTARI W-Series FOG MACHINE. Introduction Thank you for choosing an ANTARI W-Series Fog Machine. You now own a rugged and powerful state-of-the-art machine. Prior to use, we suggest that you carefully read all of the instructions. -
Page 3: Unpacking And Inspection
If your ANTARI W-508 or W-510 Fog Machine fails to work properly, discontinue use immediately. Drain all fog liquid from the tank, pack the unit securely (preferably in the original packing material), and return it to your ANTARI dealer for service. -
Page 4: Operation
Place the liquid tube into a properly filled liquid tank. Fill with high-quality, water-based fog liquid recommended by ANTARI dealer. The W-508 & W-510 only works with uncontaminated Antari FLR or FLG Fog Liquid. Any other types of liquid can damage the unit resulting in spitting and serious clogging problem. - Page 5 W-508 External View 01-Nozzle 02-Body 03-Handle 04-Handle push button 05-Tank cap & tank 06-Rocker switch / Power 07-Fuse holder 08-Power cord 09-Wireless receiver 10-Foot 11-W-1 wireless controller W-510 External View 01-Nozzle 02-Body 03-Handle 04-Tank & tank’s cap 05-PU tube & filter...
-
Page 6: Technical Specifications
Note: An optoelectronic (OPTO) liquid sensor is installed to both W-508 & W-510. The pump will automatically stop working and the LED light indicator on the rear of the machine will start to flash when there’s insufficient liquid. Please refill the liquid to the empty tank and restart (turn off then turn on) to dis-alarm the LED indicator. - Page 7 * Receiver: - The receiver is pre-equipped firmly and tested to each of the W-508 & W- 510 (rear panel), please do not try to remove it. * Functions and Setting: 1. All receivers can receive signals from any registered transmitter.
-
Page 8: Cleaning And Storage
Performance Note All fog machines develop condensation around the output nozzle. Because this may result in some moisture accumulation on the surface below the output nozzle, consider this condensation when installing your unit. All fog machines may sputter small amounts of fog occasionally during operation and for a minute or so after being turned off. - Page 9 129 - 255 = Maximum Volume Output (100%) The W-510 Fog Machine has on-board DMX control (by DIP-Switch) except on W-508. W-510 uses 1 channel to control on/off operation. Each channel has a value range of 0 to 255. On/Off function can be programmed using the DMX controller or the DMX control software being used by lighting and effects operator.
- Page 10 Addressing Each device occupies 1 channel. To ensure that the control signals are properly directed to each device, they require adressing. This is to be adjusted for every single device by changing the DIP-switches as set out in the table below. The starting address is defined as the first channel from which the device will respond to the controller.
- Page 11 Warranty Warranty shall be valid only if the product is purchased from Antari's authorized distributors or dealers. For warranty service, send the product only to an authorized distributor or dealer. All warranties are void if the product has been modified in any manner; if the product has been repaired or serviced by unauthorized personnel;...
- Page 12 For current product information visit Antari at : www.antari.com www.antari.com.tw For information requests please contact us at : sales@antari.com C08W50100...
