- Page 1 IIT Camera Systems In Image Triggering Cameras VIS-CAM 350 IIT VIS-CAM 400 IIT Document Version: A Document P/N: 10657...
- Page 3 The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be used by the purchasers of the product. JAI Inc. makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
- Page 4 Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the equipment. WARNING VIS-CAM System Installation Manual JAI Inc. 625 River Oaks Parkway San Jose, CA 95134 Tel:(408) 383-0300...
-
Page 5: Table Of Contents
IIT Camera System Manual Table of Contents Disclaimer Notice ... iii Table of Contents ... v List of Figures ... vii List of Tables ... ix Introduction ... 11 Document Overview ... 11 IIT Overview..11 IIT Camera Overview ... - Page 6 IIT Camera System Manual Table of Contents...
- Page 7 IIT Camera System Manual Figure 1. VIS-CAM 350 IIT overview ... 12 Figure 2. Block Diagram of the IIT Camera ... 12 Figure 3. Camera front with beamsplitter and fibers ... 13 Figure 4. The sensitive region of the picture area ... 13 ...
- Page 8 IIT Camera System Manual viii List of Figures...
- Page 9 IIT Camera System Manual List of Tables Table 1 Electrical Connections for the IIT Camera X2 connector ... 22 List of Tables...
- Page 10 IIT Camera System Manual List of Tables...
-
Page 11: Introduction
Output for controlling an external flash is provided if total vehicle illumination is required. The IIT camera is based on the standard JAI Traffic Solutions EN camera platform and includes a variety of picture formats: 1392 (H) x 1040 (V) -
Page 12: Iit Camera Overview
IIT Camera Overview Figure 1. VIS-CAM 350 IIT overview 1.4 Principle of Operation Figure 2. Block Diagram of the IIT Camera Introduction... -
Page 13: Figure 3. Camera Front With Beamsplitter And Fibers
IIT Camera System Manual The concept of the IIT Camera is to exploit the retro-reflective properties of the vehicle license plates. A retro-reflective surface returns the incoming light in the same direction it comes from. The IIT camera is equipped with a number of emitting infrared diodes that are positioned evenly across the camera lens. - Page 14 IIT Camera System Manual Vehicles are detected from both driving directions (front or rear shots). The system will only work if the license plate is moving through the retro-reflective sensitive region of the picture area. Other parts of the vehicle being retro-reflective can cause generation of triggers. These parts can be the tail light or stickers of different kinds.
-
Page 15: Preparing For Installation
IIT Camera System Manual Preparing for installation 2.1 Preparation for installation As mentioned in the previous section is it essential for the function of the IIT Camera that the license plate moves through the sensitive region when the vehicle passes the camera. 2.1.1 Over Lane Positioning Over lane camera mounting is always employed when the road width being monitored contains more... -
Page 16: Performance Of Trigger And Light Sensor Function
IIT Camera System Manual Figure 6. Typical Over Lane Site Layout Plan The Light Sensor and Flash shown in Figure 6 are optional. If over lane mounting is not possible the camera can be mounted at the side of the road as close to the road as possible. -
Page 17: Installation
IIT Camera System Manual Installation 3.1 Camera Dimensions Figure 7. IIT Camera Housing side view Figure 8. IIT Camera Housing front view Installation... -
Page 18: Installing The Camera
IIT Camera System Manual 3.2 Installing the Camera The camera is mounted using the same VIS Mount as VIS-CAM Systems (300/350/400). Please refer to section 3.2 in the VIS-CAM System Installation manual for camera mount template and mounting instructions. 3.2.1 Opening the Camera Housing The rear plate can be removed by loosening the two screws marked “1”... -
Page 19: Attaching The Safety Tether
IIT Camera System Manual 3.2.2 Attaching the Safety Tether A coated wire safety tether is provided for use in attaching the removable top lid to the gantry or pole. The tether has a loop at each end. First you should loop the tether around the gantry and hook one loop through the other as shown in figure A below. -
Page 20: Cable Connections
3.2.3 Cable Connections The cable connections are the same as for VIS-CAM Systems (300/350/400) but the cable entry is different as shown in the picture below. Figure 9. IIT Camera Cable Entry It is very important that the outer cable shield is connected to the rear plate at the cable entry and that the shield around the Ethernet pairs are run to the orange terminal block as shown in the picture. -
Page 21: Figure 11. Iit Camera I/O Board Layout
IIT Camera System Manual Figure 11. IIT Camera I/O Board Layout Installation... -
Page 22: Connection To J-Panel And Power Supply
Figure 12. IIT I/O Board Power and Data Connector X2 signals Table 1 Electrical Connections for the IIT Camera X2 connector X2 Pin # Wire Color White/Orange in Cat5E/6 cable Orange in Cat5E/6 Cable White/Green in Cat5E/6 Cable Green in Cat5E/6 Cable White/Blue in Cat5E/6 Cable Brown in Cat5E/6 Cable White/Brown in Cat5E/6 Cable... -
Page 23: Flash
IIT Camera System Manual 3.4 Flash The flash is optionally used for vehicle illumination at night. The electrical control signal connection to the IIT camera is from X1 on the IIT I/O Board. The signals are: Figure 13. IIT I/O Board Flash Connector X1 signals The electrical signals are the same as the VIS-CAM Systems (350/400) flash connector and the connections to the flash is as described in section 3.4 of the VIS-CAM System Installation manual. -
Page 24: System Set-Up
System Set-Up The proper way of deploying the camera, as described in section 4 of the VIS-CAM System Installation manual, also applies to the IIT Camera. The Ethernet connection to the setup PC is accessed by removing the cable between the EN Camera and the IIT I/O Board and connecting a RJ45 patch cable between the PC and the EN Camera. -
Page 25: Properties Setup When Using Built-In Light Sensor
IIT Camera System Manual 4.1 Properties setup when using built-in Light Sensor The Camera Properties for using the built-in Light Sensor Function is shown below. Figure 15. Unselect the TTL Trigger input in the Trigger section for the camera. Figure 16. Select Manual Control in the Camera ADR Control System Set-Up... -
Page 26: Properties Setup When Using External Light Sensor
Figure 17. Set the value to 1.50 by manually typing the value 4.2 Properties setup when using External Light Sensor The Camera Properties for using the external Light Sensor Function is shown below. Figure 18. Trigger Selection Unselect the Serial Trigger input and select the TTL Trigger in the Trigger section for the camera. System Set-Up... -
Page 27: Figure 19. Select Falling Edge In The Trigger Edge Select Field
IIT Camera System Manual Figure 19. Select Falling Edge in the Trigger Edge Select field Figure 20. Select Camera “ADR Control (using Light Sensor)” in the Camera ADR Control Figure 21. Set the Light Sensor IP address As described in the VIS-CAM System Installation manual section 4. System Set-Up... -
Page 28: Settings For Built-In Automatic License Plate Reader (Alpr)
Figure 22. Set the value to 1.50 by manually typing the value 4.3 Settings for built-in Automatic License Plate Reader (ALPR) 4.3.1 ALPR Parameters If the camera was purchased with built-in ALPR reader, the parameter set up is described below. Figure 23. -
Page 29: Ensetup Image And Lpr Output Capture Mode
IIT Camera System Manual Figure 25. ALPR Enabled The license plate character size must be set in accordance with the actual values. The character size can be found from the EN Setup Video Window by activating the “Freeze” buttom when a vehicle has been grabbed and then using the Measure Box to measure the height of the license plate characters. -
Page 30: Figure 27. View Tcp/Ip
IIT Camera System Manual Figure 27. View TCP/IP In order to capture images, “Capture Images” must be selected as shown below. Figure 28. Capture Images setting System Set-Up... -
Page 31: Setting The Iit I/O Board Internal Trigger Parameters
IIT Camera System Manual For more details on FTP image transfer, see section 3.2 of User’s Guide EN Camera Series Caution: ENSetup Capture Mode and FTP Transfer Mode are exclusive to each other. Both modes should not be enabled simultaneously in the camera. 4.4 Setting the IIT I/O Board internal trigger parameters A number of variables can be setup in the IIT I/O Board for optimizing performance. -
Page 32: Figure 30. Iit I/O Board Communication
IIT Camera System Manual Figure 30. IIT I/O Board communication The DAC values in commands C to J are set to 32 from the factory and it is normally not necessary to change these. The TTL Trigger pulse width is set by command A to a value between 01 and FF (255d) times 0.1 ms. -
Page 33: Figure 31. Iit Camera Trigger Generation Principle
IIT Camera System Manual Figure 31. IIT Camera Trigger Generation Principle System Set-Up... -
Page 34: Appendix A: Troubleshooting
(command M) via Serial Terminal in EN Setup application in accordance with camera specific values Contact JAI Inc. See section 4.3 Set the clock in the camera correctly. The clock can be synchronized to PC time or an NTP server. -
Page 35: Appendix B: Focus Adjustment Of Kowa 35Mm
IIT Camera System Manual Appendix B: Focus Adjustment of Kowa 35mm The following describes the adjustment of the 35mm Kowa lens for best day/night performance using IIT IR Illuminator for night illumination. 1) Disconnect IR Illuminator from IIT IO Board connector X11: Figure 32. -
Page 36: Appendix C: Vis-Cam 400 Iit-2030 And Vis-Cam 400 Iit-2076
Appendix C: VIS-CAM 400 IIT-2030 and VIS-CAM 400 IIT-2076 The VIS-CAM 400 IIT-2030 and VIS-CAM 400 IIT-2076 are made a little different from the VIS-CAM 350 IIT cameras. The picture below shows the VIS-CAM 400 IIT overview Figure 34. VIS-CAM400IIT-2030 and VIS-CAM400IIT-2076 overview Note: The TS-9725EN camera is not powered. -
Page 37: Appendix D: Connection To Tnc-100 Floodlight
IIT Camera System Manual Appendix D: Connection to TNC-100 Floodlight The connection of TNC-100 floodlight for night time visible constant illumination is shown below. Figure 35. Connection to TNC-100 for VIS-CAM 400 IIT The on and off switching point are set via the camera properties in the EN Setup. The typical values are shown below. -
Page 38: Appendix E: Iit I/O Board Default Settings
Appendix E: IIT I/O Board default settings The table below shows the default settings for microcontroller U12 on the I/O Board. The settings are accessible from the EN Setup via Serial Communication Terminal – Laser (IIT I/O Board). Inquiry syntax: #<command><CR> Change value syntax: #<command><hex-value><CR>... - Page 39 IIT Camera System Manual Besides these constants there are some commands for test purposes. These are: Name Disable checksum Show input vector IR Illuminator off IR Illuminator on Firmware version Below are the settings for the microcontroller U1 on the I/O Board. This processor controls the camera heater, fan and power supply for the camera.
- Page 40 Besides these constants there are some commands for test purposes. These are: Name Disable checksum Firmware version Status request Syntax Description Disables checksum commands until next $u99<CR> power down $V<CR> Shows the installed firmware version for U1 The format of the answer is $S<temperature><temperature status><fan stauts><heater status><CR>...
-
Page 41: Appendix F: Quick Start Guide
IIT Camera System Manual 10 Appendix F: Quick Start Guide Description Find a place to mount the camera in a position where the vehicles will be passing through the reflection sensitive part of the picture Sec. 1.5 Make sure that the geometry is correct: Max height 7m Angle 20°... - Page 42 Connect the camera to the Ethernet port of an appropriate test PC. Switch on the camera power. Launch EN Setup application Sec. 4 Align camera mechanically to correct position by adjusting the VIS Mount and using the tools from EN Setup.
