Add: 3: presents the POWER address.
V: 36: presents the defined voltage max value.
A: 3: presents the defined current max value.
W: 108: presents the defined power max value.
Sending: presents the operation state.

4.15 Logout User

Click the icon
It main includes the information about the Http and the e-mail addresses of Array Electron Company and so on.
Select the icon
for the operation. When leaving, the user must carry out the canceling operation, especially the manager.
4.16 Power Supply State Indication
1. Overloading current indication:
Blue presents normal.
2. Overloading power indication:
Blue presents normal.
3. Power supply ON/OFF state
Blue presents OFF.
4.Power supply control type:
Blue presents CONROL SELF.
4.17 Exit the System
Select the icon
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
and the help diagram as shown in Fig. 3-26 will be displayed.
Fig. 4-27 Help Interface
and the system will automatically be in the lowest limit of authority. User must login again
Red presents overloading.
Red presents overloading.
Red presents ON.
Red presents PC CONTROL.
. To do this, you must login first, otherwise the system cannot be closed.
