2.3.4 Store data function

To users, this is a good function for ease using. If you wan to use a constant voltage and
current as 24V and 2A, or 12V and 2.3A etc every day, you just need to set up the data for the
first time, and then store the data in the power supply, and then recall it when you need the data
again. It can store 10 sets data at most.
The stored contents include 1) Voltage value; 2) Current value; 3) Maximum voltage; 4)
Locked/unlocked key board; 5) Maximum power ; 6)Baud rate; 7) Communication address.
The store operation always be done after setting up V-set, I-set etc, the operation is as following:
Procedure
Step 1
Step 2
Step 3
Step 4
Step 5
For example, set up the voltage=15V, current=2A, Maximum output voltage=18V, key board
locked, Maximum output power=25W, Baud rate=9600, communication address=05, after done
the setup , users can store all the above setup as a set of data, such as the 01 or 02 etc set date.
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
The operation Methods
Press "Store" button
Enter the password ( Or jump to step 4 if the keyboard
is unlocked)
Press "Enter" button ( it will return to step 2 if your
password is wrong for reentering)
Enter the set value for store number(from 1 to 10) by
using the number key or rotate the rotary button to
change the set value number for store
Press "Store" button to confirm the set value, if the
number is out of the range from 1 to 10, it will retune to
Step 2 for reenter
It will exit the store operation at any procedure by press ESC button
3645A-TYPE USER'S MANUAL
LCD display
****V ****W
****A **
ENTER PASSWORD
ENTER PASSWORD
1234
STORE 1
STORE *
10
