"Show": Show the interface.
"Hide": Hide the interface.
"Start Communicate": Start the communication.
"Stop Communicate": Stop the communication.
"About PMS": Show the help contents.
"Exit System": Close the system. (And users must register before.)
2. If the system is started from the program file folder, it will be at the maximized state.
3. System Uninstallation
It is only need to select "
closing of the system otherwise there will be no way to uninstall.

4.1 Users' Login

When the system is first entered, it is set to be in the lowest limit of authority state. At this time, only the COM
port set and the POWER selection can be carried out, and other function cannot be used. So users must login and
operate and it guarantees the security of the system.
Select the icon
the system will provide with two users: the "Manager" and the "Lowest" for you to select. Selecting "Manager",
entering the password "0001" and then clicking "OK", in this way the system will have all the functions.
Explanation: "Manager" is the user of management; "Lowest" is the user of the lowest limit of authority. And
the two users are retained by the system.

4.2 The Definition of the Power Supply

Select the function item
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
"in the program file folder. And it must be done after the

Chapter 4 The Function Introduction

and the interface as shown in Fig. 4-1 will be displayed. After the first time installation,
Fig.4-1 The User Login Interface
and then the interface as shown in Fig. 4-2 will be displayed.
Fig. 4-2 The Power Definition Interface
