- Page 1 USER’S MANUAL SWITCHING-MODE DC POWER SUPPLY ARRAY 366XA ARRAY ELECTRONIC...
- Page 2 ARRAY 366XA SWITCHING-MODE DC POWER SUPPLY ARRAY 366XA is a series of 500W programmable switching-mode DC power supplies with RS-232, USB (optional) and GPIB (optional) interfaces. The good durability, simple operation, low noise, excellent output accuracy as well as the adjustment from 0V make this series of reliable power supplies the right choice for many applications.
- Page 3 The Front Panel at a Glance 1. AC power switch 2. Sense terminals 3. Earth ground terminal 4. Supply output terminals 5. Output on/off key 6. Left/Right key 7. Control knob 8. Up/Down key 9. Menu setting key 10. Voltage setting key 11.
- Page 4 12. Switch key for second function : Enables the second function of other keys. 13. Store key for second function (Save): Stores the present operating states in location “0”, “1”, … “9”. 14. Recall key for second function (Recall): Recalls a previously stored operating state from location “0”, “1”,…“9”.
- Page 5 The Rear Panel at a Glance 1. AC inlet 2. Fuse holder 3. RS-232 interface connector 4. GPIB or USB interface connector (optional) 5. Fan outlet An Introduction to this Manual General Information Apart from a general description of your power supply, it provides instructions for checking your power supply, selecting power-line voltage and connecting to AC power.
- Page 6 Tutorial It describes basic operation of the power supply and gives specific details on the operation and use of ARRAY 366XA power supplies. Specifications It lists the power supply’s basic specifications.
-
Page 7: Table Of Contents
Contents Chapter 1 General Information ……………………………………...... 11 General Information………………………………………………………………… 11 Safety Considerations………………………………………………….. ………… ...11 Description……………………………………………………………...... 11 Installation……………………………………………………………………………12 Initial Inspection……………………………………………………….......12 Mechanical Check……………………………………………………………………12 Electrical Check……………………………………………………………………12 Temperature Control………………………………………………………………… 12 Rack Mounting……………………………………………………………………….13 Chapter 2 Initial Operation ………………………………………………………..14 Initial Operation ……………………………………………………………………..14 Preliminary Checkout………………………………………………………………..14 Power-Line Cord……………………………………………………………………..14 Fuse Replacement……………………………………………………………………15 Power-On Checkout………………………………………………………….15 Self-test started……………………………………………………………….15... - Page 8 Menu Setting ………………………………………………………………………24 Main Menu Description…………………………………………………………….24 Storing and Recalling………………………………………………………………24 Error Messages Display…………………………………………………………….25 Local/ Remote Operation Switch…………………………………………………..25 Protection Function…………………………………………………………………26 Abnormal Latched State Clearance…………………………………………………26 Over-Voltage…………………………………………………………………………26 Over-Temperature…………………………………………………………………….26 The Power Supply Calibration……………………………………………………….27 Calibration Instrument………………………………………………………………..27 Cautions……………………………………………………………………………..27 Calibration Procedures………………………………………………………………27 Chapter 4 Remote Interface Reference ………………………………………….31 Remote Interface Reference………………………………………………………….31 SCPI Command Summary…………………………………………………………31 An Introduction to the SCPI Language…………………………………………….32 Command Format Used in This Manual……………………………………………33...
- Page 9 SCPI Confirmed Commands…………………………………………………….55 Device-Specific Commands………………………………………………………57 Chapter 5 Application Programs………………………………………………….58 Application Programs………………………………………………………………...58 RS-232 Operation Using QuickBACSIC ………………………………………….58 Chapter 6 Tutorial………………………………………………………………….59 Tutorial……………………………………………………………………………….59 An Overview of ARRAY 366XA Operation…………………………………………59 Output Characteristics………………………………………………………………59 Unregulated State…………………………………………………………………….60 Unwanted Signals…………………………………………………………………….60 Connecting the Load………………………………………………………………..61 Output Isolation………………………………………………………………………61 Multiple Loads……………………………………………………………………..61 Considerations……………………………………………………………………….62 Capacitive Load……………………………………………………………………..62...
- Page 10 APPENDIX Error Messages …………………………………………………68 Error Messages…………………………………………………………………….68 Execution Errors…………………………………………………………………….68 Self-Test Errors……………………………………………………………………….71 Calibration Errors ……………………………………………………………………72...
-
Page 11: Chapter 1 General Information
ARRAY 366XA is a series of programmable switching-mode DC power supply with stable voltage and constant current. The excellent line and load regulation, extremely low ripple and noise make it well suited as a high preference power system. 366XA, as a kind of high-efficient switching-mode supply, features wide supply input voltage from 100-240AC, high power factor and a minimum output of 0V. -
Page 12: Installation
Keep the original packing materials in case the power supply has to be returned to Array for repairing in the future. If you return the power supply for service, please attach a tag identifying the owner and model number. A brief description of the malfuction is also needed. -
Page 13: Rack Mounting
the over-temperature protection may take effect, depending on the input voltage and output power. A brushless fan is used to cool the power supply by drawing cool air through the two sides and exhausting the heat through the fan outlet on the rear panel. Sufficient space must be left at the rear and two sides of the cabinet for air circulation when the power supply is installed. -
Page 14: Chapter 2 Initial Operation
Preliminary Checkout ARRAY 366XA power supply can be used from a rated 100 V to 240 V single phase AC power source at 47 to 63 Hz. There is an indication below the AC power inlet on the rear panel showing the rated input voltage set for the power supply at the factory. -
Page 15: Fuse Replacement
Fuse Replacement 1 Replace the fuse Step 1: Remove the fuse-holder below AC power inlet. Step 2: Replace the fuse with the correct one that meets the requirements. Step 3: Put back the fuse holder. For 115V AC operation, 10AT fuse must be used; For 230V AC operation, 6AT fuse must be used. -
Page 16: Power-On Checkout
Power-On Checkout The power-on test includes an automatic self-test that checks the internal microprocessors and a system self-test after the power supply is turned on, and examines the information relate to self-test process shown on the front panel. You will observe the following sequence on the display: 1. -
Page 17: Output Checkout
Output Checkout The output checkout is to ensure that the power supply develops its rated outputs and properly responds to various operations. Specific steps are shown as followings: Voltage Output Checkout 1. Turn on the power supply. Press the “Power-on” button, and finish the power-on checkout. Usually the power supply will go into the power-on / reset state automatically. - Page 18 Current Output Checkout 1. Turn on the power supply. Press “Power-on” button and finish the power-on checkout. Usually the power supply will go into the power-on / reset state automatically and the “OFF” annunciator in the lower right corner of the LCD turns on. Both the voltage value and current value are 0.
- Page 19 6. Ensure that the current can be adjusted from 0A to the maximum rated value. Adjust the knob until the ammeter indicates 0A and then until the ammeter indicates the maximum rated value. If an error has been detected during the output checkout procedures, the ERROR annunciator will turn on.
-
Page 20: Chapter 3 Front Panel Operation
Chapter 3 Front Panel Operation Front Panel Operation 3.1 Front Panel Operation Overview • Output on/off • Constant Voltage setting • Constant Current setting • Menu Setting • Storing and Recalling • Error Messages Display • Local/Remote Operation switch • Protection Function •Power Supply Calibration 3.2 Output on/off The output of the power supply could be switched on or off through this... -
Page 21: Constant Voltage Output Setting
When it is operated from remote interface, inputting the following command can enable or disable the output: OUTPUT ON/OFF. You can turn on the output by selecting ON and turn off the output by selecting OFF. 3.3 Constant Voltage Output Setting Constant voltage output is the most common output of the power supply. -
Page 22: Enabling The Outputs
② Input the desired current value by pressing number keys. “Clear” key can be used to clear the wrong value to input again. ③ Press “Enter” key to confirm the current setting value. 2). Using “Left/Right” keys, knob and “Enter” key to input: ①... -
Page 23: Setting The Desired Output Current
② Press “Left/Right” keys to move the blinking digit to the corresponding digit of the value. ③ Increase or decrease the relevant value by turning the knob clockwise or counter clockwise, then use “Left/Right” keys to move to the next digit to modify. ④... -
Page 24: Menu Setting
3.4 Menu Setting 3.4.1 Main Menu Description Press “Menu” key to enter into main menu, which is showed as follows: Function and Parameter Description Current Limit: Current Limit： 14.600A Current Limit Value Voltage Limit: Voltage Limit： 35.200V Voltage Limit Value Voltage Over: Voltage Over：... -
Page 25: Error Messages Display
recall condition, the voltage and current values stored previously can be retrieved from corresponding EEPROM and set as present values. Example 1: Set voltage to 5V and current to 2A. Then turn on the power supply and save this state to the EEPROM specified by Location 1. Step Operational Details Display Information... -
Page 26: Protection Function
this state as soon as it is switched on. In remote control state, all keys and knobs become invalid (except “2nd” and “Local” keys). When the power supply receives the remote command (SYST:REM) through RS232 Interface or commands through GPIB Interface, annunciator will be on and remote control becomes valid. -
Page 27: The Power Supply Calibration
normal range. The Power Supply Calibration Because various factors may cause the reduction of the power supply’s output precision after it has been used for a period of time, the user should calibrate the power supply’s output to make the output return to the previous precision. But it is suggested that the power should not be calibrated frequently. - Page 28 In this mode, three voltage points: 0.5V、22V、34.5V should be calibrated. 3.1.1 Wiring OUTPUT KEITHLEY 2000 366XA SENSE 3.1.2 0.5V Calibration Press “Enter” key, you will see the following figure in the display: Input the value you read from KEITHLEY 2000, which is retained to four decimal places.
- Page 29 “Enter” key to confirm and exit to calibration menu. Now, voltage calibration is completed. 3.2 CC Mode Calibration In this mode, three current points: 0.5A、6A、9A should be calibrated. 3.2.1 Wiring +10A OUTPUT FLUKE45 366XA 3.2.2 0.5A Calibration Press “Enter” key, you will see the following figure in the display:...
- Page 30 Input the value you read from , which is retained to four decimal places. FLUEK 45 Press “Clear” key to remove the wrong input value of present digit. Then press “Enter” key to confirm. 3.2.3 6A Calibration Press “Enter” key to verify and then you will see the followings: Input the value you read from , which is retained to four decimal places.
-
Page 31: Chapter 4 Remote Interface Reference
Chapter 4 Remote Interface Reference Remote Interface Reference A detailed description of how to use the remote interface will be given in this chapter, which includes how to program the power supply through the remote interface, the commands format and matters need attention. SCPI Command Summary Simplified Programming Overview Using the Apply Command... -
Page 32: An Introduction To The Scpi Language
An Introduction to the SCPI Language SCPI (Standard Commands for Programmable Instruments) is an ASCII-based instrument command language designed for test and measurement instruments. The detailed techniques used to program the power supply over the remote interface are introduced in the following sections. SCPI commands are based on a hierarchical structure, also known as a tree system. -
Page 33: Command Format Used In This Manual
Command Format Used in This Manual The format used to show commands in this manual is shown below: CURRent {<current>|MINimum|MAXimum} The command syntax shows most commands are the mixture of upper- and lower-case letters. The upper-case letters indicate the abbreviated spelling for the command. -
Page 34: Command Separators
Command Separators A colon “ ：” is used to separate a command keyword from a lower-level keyword as shown below: SOURce:CURRent:TRIGgered A semicolon “ ；” is used to separate two commands within the same subsystem as shown below: SOUR:VOLT MIN;CURR MAX The following two commands have the same effect as the above command. -
Page 35: Scpi Command Terminators
You can also query the minimum or maximum value allowed with the present function as follows: CURR? MAX CURR? MIN SCPI Command Terminators A command string sent to the power supply must terminate with a <new line> character. The IEEE-488 EOI (end-or-identify) message is interpreted as a <new line> character and can be used to terminate a command string in place of a <new line>... -
Page 36: Output Setting And Operation Commands
double quote. You can include the quote delimiter as part of the string by typing it twice without any characters in between. The following command uses a string parameter: DISPlay:TEXT <quoted string> Output Setting and Operation Commands APPLy [{<voltage>|DEF|MIN|MAX}][,{<current>|DEF|MIN|MAX}]] APPLy? MEASure :CURRent[:DC]? [:VOLTage][:DC]? -
Page 37: Calibration Commands
[:STATe] {OFF|ON} [:STATe]? :TEXT[:DATA] <quoted string > :TEXT[:DATA]? :TEXT:CLEar SYSTem :BEEPer[:IMMediate] :ERRor? :VERSion? *IDN? *RST *TST? *SAV {1|2|3} *RCL {1|2|3} Calibration Commands CALibration :COUNt? :CURRent[:DATA] < numeric value > :CURRent:LEVel {MIN|MAX} :SECure:CODE <new code > :SECure:STATe {OFF|ON},<new code> :SECure:STATe? :STRing <quoted string > :STRing? :VOLTage[:DATA] <... -
Page 38: Rs-232 Interface Commands
Some of them are the SCPI-confirmed commands, and some are the device-specific commands. It is unnecessary to differentiate them when using ARRAY 366XA. Using the APPLy Command The APPLy command provides the most straightforward method to program the power supply over the remote interface, such as to control one output or triple outputs of power supply, and to read the immediate output value of each supply. -
Page 39: Selecting A Trigger Source
CURR 2.0 The two commands shown in this example has the same function as the first command shown in the above example, which shows when some individual parameter is changed, there is no need to enter the whole setting parameters as the above example, just enter some specified parameter. -
Page 40: Output Setting And Operation Commands
can set the output current value of the specified supply. For the setting range, please consult the relevant current parameters listed in the table of “Programming Ranges and Output Identifiers” section. When the voltage and current are set, the “DEF|MIN|MAX” represents the default value, the minimum value and the maximum value respectively. -
Page 41: Output On/Off And Tracking Operation Commands
Output on/off and Tracking Operation Commands Output[:STATe] {OFF|ON} This command enables or disables the outputs of the power supply. For example： OUTPUT ON Enable the outputs OUTPUT OFF Disable the outputs Output[:STATe]? This command queries the output state of the power supply and returns the corresponding values. - Page 42 which is a stored value and transferred to the output terminals when a trigger occurs. A pending triggered level is not affected by subsequent CURRent commands. [SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX] This query checks and returns the presently programmed triggered current level. If no triggered level is programmed, present CURRent value is returned.
-
Page 43: Trigger Source Choice
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX] This query checks and returns the presently programmed triggered voltage level. If no triggered level is programmed, the VOLTage value is returned. VOLTage:TRIGgered? Return the VOLTage value or the set triggered voltage level of the selected output VOLTage:TRIGgered? MAX Return the maximum programmable voltage values of the selected output VOLTage:TRIGgered? MIN Return the minimum programmable voltage values of... -
Page 44: Immediate Triggering
if any delay is given. 3. You can also select the trigger source from the USB, RS-232 or GPIB interface. The operation has been introduced before. Immediate Triggering 1. Select the internal immediate trigger source by sending the following command: TRIGger:SOURce IMM 2. - Page 45 messages are not sent to the display and all annunciators are disabled except the “ERROR” and “Rmt” annunciators. The display state is automatically turned on when you return to the local mode. After pressing the “Local” key to return to the local state from the remote interface, press any key except for the number keys, knobs, “Resolution”, “Clear”, ”Enter”, and “Track”...
- Page 46 For example: ARRAY,3662A,0,1.3-1.0-1.5 *RST This command resets the power supply to its power-on state.
-
Page 47: Calibration Commands
Calibration Commands CALibration:COUNt? This command queries the power supply to determine the number of times it has been calibrated. CALibration:CURRent[:DATA] <numeric value> This command can only be used after calibration is unsecured. It enters a current value of a selected output that you obtained by reading an external meter. You must first select a calibration level (CAL:CURR:LEV) for the value being entered. -
Page 48: Rs-232 Interface Commands
are then stored in internal memory. CALibration:VOLTage:LEVel {MINimum | MAXimum} Before using this command, you must select the output which is to be calibrated by INSTrument command. This command can only be used after calibration is unsecured. It sets the power supply to a calibration point that is entered with CALibration:VOLTage[:DATA] command. -
Page 49: What Is An Enable Register
not clear bits in event registers. Querying an event register returns a decimal value which corresponds to the binary-weighted sum of all bits set in the register. What is an Enable Register? An enable register defines which bits in the corresponding event register are logically ORed together to form a single summary bit. -
Page 50: The Questionable Status Register
QUEStionable Status Event Registers Enable Registers VOLTage CURRent Not used Not used Output Buffer TEMPerature Not used Not used “OR” Not used Not used OVERvoltage Not used Not used Not used Not used Not used Status Byte Not used Event Registers Enable Registers STAT:QUES? STAT:QUES:ENAB <value>... -
Page 51: The Standard Event Register
Decimal Definition Value The power supply is in constant 0(Voltage) voltage mode. The power supply is in constant 1(Current) voltage mode. Always set to 0. 2-3(Not used) The fan has a fault condition. 4(Over-temperature) Always set to 0. 5-8(Not used) power supply 9(Over Voltage) - Page 52 Bit Definitions - Standard Event Register Decimal Definition Value Operation Complete. All commands prior 0 OPC to and including an *OPC command have been executed. 1 not used Always set to 0. Query Error. The power supply tried to read the output buffer but it was empty. Or, new command line was received before a previous query had been read.
-
Page 53: The Status Byte Register
The Status Byte Register The status byte summary register reports conditions from the other status registers. Query data that is waiting in the power supply’s output buffer is immediately reported through the “Message Available” bit (bit 4) of status byte register. Bits in the summary register are not latched. - Page 54 queue. The additional errors will not be stored. 1. Errors are stored and retrieved in first-in-first-out (FIFO) order. The first error returned is the first error that was stored. When you have read all errors from the queue, the “ERROR” annunciator turns off. 2.
-
Page 55: Scpi Conformance Information
*OPC This command sets the “Operation Complete” bit (bit 0) of the standard event register after the command is executed. *PSC { 0 | 1 } (Power-on status clear.) This command clears the status byte and the standard event register enable masks when power is turned on (*PSC 1). When *PSC 0 is in effect, the status byte and standard event register enable masks are not cleared when power is turned on. - Page 56 DISPlay [:WINDow][:STATe] {OFF|ON} [:WINDow][:STATe]? [:WINDow]:TEXT[:DATA] <quoted string > [:WINDow]:TEXT[:DATA]? [:WINDow]:TEXT:CLEar MEASure [:SCALar]:CURRent[:DC]? [:SCALar] :VOLTage[:DC]? OUTPUT [:STATe] {OFF/ON} [:STATE]? [SOURce:] CURRent[:LEVel][:IMMediate][:AMPLitude] {<current>|MIN|MAX} CURRent[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX] CURRent[:LEVel]:TRIGgered[:AMPLitude] {<current>|MIN|MAX} CURRent[:LEVel]:TRIGgered[:AMPLitude]?[MIN|MAX] VOLTage[:LEVel][:IMMediate][:AMPLitude] {<voltage>|MIN|MAX} VOLTage[:LEVel][:IMMediate][:AMPLitude]?[MIN:MAX] VOLTage[:LEVel]:TRIGgered[:AMPLitude] {<voltage>|MIN|MAX} VOLTage[:LEVel]:TRIGgered[:AMPLitude]?[MIN|MAX] STATus :QUEStionable[:EVENt]? :QUEStionable:ENABle <enable value> :QUEStionable:ENABle? :QUEStionable:ENABle <enable value> SYSTem :BEEPer[:IMMediate] :ERRor?
-
Page 57: Device-Specific Commands
Device-Specific Commands The following commands are specific to the ARRAY 366XA power supply. However, these commands are designed with the SCPI Command in mind and they follow all of the syntax rules defined by the standard command. List as follow: APPLy [{<voltage>|DEF|MIN|MAX>}[,{<current>|DEF|MIN|MAX}]]... -
Page 58: Chapter 5 Application Programs
' Set the cursor at the first line of the first row DIM Recv$(100) ' Restore and receive the data array OPEN "COM1:9600, N, 8, 2, RS, LF, PE" FOR RANDOM AS #1 LEN = 1000 ' Baud Rate: 9600... -
Page 59: Chapter 6 Tutorial
Chapter 6 Tutorial Tutorial The ARRAY 366XA is a high performance instrument capable of delivering clean dc power. But to take full advantage of the performance characteristics designed into the power supply, certain basic precautions must be observed when it is connected for use on the lab bench or as a controlled power supply. -
Page 60: Unregulated State
Figure below shows the operating modes of the three outputs of the power supply. The operating point of one supply will be either above or below the line RL = RC. This line represents a load where the output voltage and the output current are equal to the voltage and current setting. -
Page 61: Connecting The Load
And the noise across the output terminals is of very low value in the ARRAY 366XA. The noise from the terminals to earth ground can be a problem for very sensitive circuitry that is referenced to earth ground. When a circuit is referenced to earth ground, a low level line-related AC current will flow from the output terminals to earth ground. -
Page 62: Considerations
Extending the output The ARRAY 366XA provides corresponding outputs, and enables the power supply to provide voltages or currents greater than its rated maximum outputs with different... -
Page 63: Reliability
Series operation of two or more power supplies can obtain a higher voltage output than that is available from a single supply. Series connected power supplies can be operated with one load across power supplies. The power supply has a related internal protection function so that if operated in series with other power supplies, damage will not occur when the load is short-circuited or the series-wound power supply are not turned on simultaneously. -
Page 64: Chapter 7 Specifications
Chapter 7 Specifications Specifications The performance specifications of ARRAY 366XA are listed in this chapter in details (Specifications are warranted in the temperature range of 25±2℃ with a resistive load.). Please consult the relevant data in actual use. Performance Specifications... -
Page 65: Transient Response Time
Current Readback Resolution Voltage Current Meter Resolution Voltage Current Transient Response Time Less than 1ms for output to recover to within 100 mV following a change in output current from full load to half load or vice versa Command Processing Time Programming Commands: Maximum time for output to change after receiving APPLy and SOURce commands: <50msec Readback Command: Maximum time to readback output MEASure? command:... - Page 66 Voltage Programming Speed Maximum time required for output voltage to settle within 1% of its total excursion (for resistive load). Command processing time is excluded. 3662A 3663A 3664A Full load Up 20msec 22msec 22msec Full load Down 22msec 22msec 22msec 20msec 20msec 22msec...
-
Page 68: Appendix Error Messages
APPENDIX Error Messages Error Messages When the front-panel ERROR annunciator turns on, and the power supply generates a short beep, one or more command syntax or hardware errors have been detected. A record of up to 20 errors is stored in the power supply’s memory. Errors are stored and retrieved in first-in-first-out (FIFO) order. - Page 69 colon, semicolon, or blank space with a comma or you may have replaced a comma with a blank space. Example: TRIG:SOUR,BUS or APPL P6V 1.0 1.0 -104 Data type error The wrong parameter type was found in the command string. You may have specified a number where a string was expected, or vice versa.
- Page 70 -138 Suffix not allowed A suffix was received following a numeric parameter which does not accept a suffix. Example: STAT:QUES:ENAB 18 SEC (SEC is not a valid suffix). -144 Character data too long The character data element contained too many characters. -151 Invalid string data An invalid character string was received.
-
Page 71: Self-Test Errors
output buffer is cleared when power has been off, or after a *RST (reset) command has been executed. -420 Query UNTERMINATED The power supply was addressed to talk (i.e., to send data over the interface) but a command has not been received which sends data to the output buffer. For example, you may have executed an APPLy command (which does not generate data) and then attempted an ENTER statement to read data from the remote interface. -
Page 72: Calibration Errors
Calibration Errors Code Explanation Cal secured The calibration is secured. Invalid secure code An invalid calibration security code was received when attempting to unsecure or secure the power supply. You must use the same security code to unsecure the power supply as what was used to secure it, and vice versa. - Page 73 Cal checksum failed, store/recall data in location 8 Cal checksum failed, store/recall data in location 9...
